• Command table

Command Sub command
00 — Send frequency data
Same as Send mode data
01
command 06
02 — Read band edge frequencies
03 — Read operating frequency
Same as Read operating mode
04
command 06
05 — Set frequency data
1
00* Set LSB
1
01* Set USB
1
02* Set AM
1
03* Set CW
1
06 04* Set RTTY
1
05* Set FM
1
07* Set CW-R
1
08* Set RTTY-R
1
11* Set S-AM
07 — Select VFO mode
— Select memory mode
08
2
0001 – 0101* Select memory channel
*
09 — Memory write
0A — Memory to VFO
0B — Memory clear
00 Scan stop
01 Programmed/memory scan start
02 Programmed scan start
04 Auto memory write scan start
22 Memory scan start
0E
23 Select memory scan start
B0 Set as non-select channel
B1 Set as select channel
D0 Set scan resume OFF
D3 Set scan resume ON
00 10 Hz (1 Hz) tuning step
01 100 Hz tuning step
02 1 kHz tuning step
03 5 kHz tuning step
04 6.25 kHz tuning step
05 9 kHz tuning step
10
06 10 kHz tuning step
07 12.5 kHz tuning step
08 20 kHz tuning step
09 25 kHz tuning step
10 100 kHz tuning step
11 1 MHz tuning step
Description
1
* Add 00, 01 or 02
for selecting wide,
normal or narrow
filter, respectively.
2
P1=0100, P2=0101
CONTROL COMMAND
Command Sub command
00 Attenuator OFF
11
20 Attenuator ON
00 Select [ANT1]
12
01 Select [ANT2]
00 Announce with voice synthesizer
13 01 (00=all data; 01=frequency and
02 S-meter level; 02=receive mode)
01 + level data [AF] level setting (0000=max.
CCW to 0255=max. CW)
02 + level data [RF] level setting (0000=max.
CCW to 0255=11 o'clock)
03 + level data [SQL] level setting (0000=11
o'clock to 0255=max. CW)
06 + level data [NR] level setting (0000=min. to
14
0255=max.)
07 + level data Inside [TWIN PBT] setting
(0000=max. CCW, 0128=center,
0255=max. CW)
08 + level data Outside [TWIN PBT] setting
(0000=max. CCW, 0128=center,
0255=max. CW)
09 + level data [CW PITCH] setting (0000=low
pitch to 0255=high pitch)
01 Read squelch condition
15
02 Read S-meter level
02 Set preamp (00=OFF;
01=preamp 1; 02=preamp 2)
12 Set AGC time constant (00=OFF;
01=S-fast; 02=fast; 03=slow)
16
22 Set noise blanker (00=OFF; 01=ON)
40 Set optional noise reduction
(00=OFF; 01=ON)
41 Set optional auto notch
(00=OFF; 01=ON)
18 00 Turn the receiver power ON
01 Turn the receiver power OFF
19 00 Read the receiver ID
1A 00 + data Send/read memory contents
(See example 1 on p. 42)
01 + data Send/read IF filter setting
(See example 2 on p. 42)
02 + data Send/read set mode contents
(See example 3 on p. 43)
14
Description
