Troubleshooting - Icom IC-T2H Instruction Manual

If your transceiver seems to be malfunctioning, please check
the following points before sending it to a service center.
PROBLEM
No power comes on. • The battery is exhausted.
(A slight current flows in the circuits even when the
power is off.)
Transmitting is impossible. • The battery is exhausted.
Frequency cannot be set. • Memory mode, call channel or channel indication
mode is selected.
• The lock function is activated.
Scan does not function. • The same frequencies are programmed into both
scan edges.
• Only CH1 is programmed; or, all other memory
channels are set as skip channels.
[Y] or [Z] keys do not • Memory channels 1 and/or 2 are not pro-
function when using the grammed and simple mode is selected.
optional HM-75A.
Squelch does not open for • Tone squelch is activated.
received signals.
Some memory channels • Some memories have been cleared or the num-
cannot be selected. ber of active memories has been reduced.
ANI mode cannot be ac- • ANI mode can only be accessed through cloning.
cessed.
Some functions are not • The desired function(s) has not been assigned to
available. a key.
POSSIBLE CAUSE

TROUBLESHOOTING

SOLUTION
• Charge the battery pack or place new dry cell bat-
teries in the battery case.
(Remove the battery pack if you will not be using the trans-
ceiver for a long time.)
• Charge the batteries or place new dry cells in the
battery case.
• Push [ V] to select VFO mode; or, turn power on
A
while pushing [Y] + [0] to exit channel indication.
• Set [ L] down to deactivate the lock function.
D
• Program different frequencies.
• Program additional memories; or, cancel skip set-
tings for one or more channels.
• Program the memory channels or set to microphone
normal.
• Turn off the tone squelch.
• Program the cleared memories or increase the num-
ber of active memory channels.
• Set ANI operation using the CS-T2
.
WARE
• Set the desired function(s) using Key Customize
mode.
13
REF.
pgs. 9,
10
pgs. 9,
10
pgs. 11
p. 13
p. 19
p. 25
pgs.
19, 28
p. 26
pgs.
19, 30
- p. 36
CLONING SOFT
p. 31
37
