D Via the keypad
(other band directly)
Push [VFO] to select VFO
mode.
Push 6 digit keys, starting
from the 100 MHz digit.
• The operating band changes
automatically.
• It's not necessary to input the
decimal point.
D Other methods
VIA THE DIAL: Rotate [DIAL] to change the frequency ac-
cording to the set tuning steps.
USING THE MHz STEP: Push [
rotate [DIAL] to change the frequency in one MHz steps.
4
4
0
0
0
0
MHz] for 1 sec., then
(VFO)

Setting tuning steps

This transceiver has 8 tuning steps (VHF and UHF bands
have independent settings) as follows:
• 5 kHz • 10 kHz • 12.5 kHz
• 20 kHz • 25 kHz • 30 kHz
Push [VFO] to select VFO mode.
Push [BAND] to select the VHF or UHF band.
Push [ SET] for 1 sec. to enter set mode.
(H/L)
Push [TONE] or [H/L] several times until "TS" appears.
Rotate [DIAL] to select the desired tuning step.
Push [ CLR] to exit set mode.
(VFO)
For convenience, select a tuning step that matches the fre-
quency intervals of repeaters in your area.
[DISPLAY EXAMPLE]
15 kHz tuning step
3
BASIC OPERATION
SET MODE
USING
• 15 kHz
• 50 kHz
25 kHz tuning step
