General specifications (HP setup):
Wingspan:
Lenght:
Height:
Wing area:
Wing loading:
Center of gravity:
Airfoil:
Print weight (PLA):
Empty weight (w/o battery):
Takeoff weight (6s 2700 lipo):
Max takeoff weight:
Never exceed speed, VNE:
Design maneuvering speed, VA:
Stall speed, VS:

Recommended setup

Motor: Turnigy SK3 5055 430KV (for 6S setup)
or any 5055 430 - 380grams motor (for 6s setup)
ESC: 80A 6s with UBEC or any 6s 60-100A + connector suitable for battery.
Battery: 2700 - 3300 mAh 6S or any 6s (500-600g)
Propeller: wooden 15" x 6"
printed PET motor mount

Performance measurement

Max speed VH (level flight):
Rate of climb:
Flight time (6s 2700mAh):
... print your plane | www.3DLabPrint.com
1442 mm / 56.8 inch
1094 mm / 43.1 inch
433 mm / 17.0 inch
54,5 dm2 / 7.0 square foot
59 g/dm2 / 19.0 oz/square foot
120 mm from leading edge
of upper wing
special LHK mod. by 3DLabPrint
2358 g / 83.2 oz
2800 g / 98.7 oz
3230 g / 113.9 oz
3500 g / 123.46 oz
100 km/h / 49 mph
60 km/h / 31 mph
25 km/h / 9.4 mph
65 km/h – 35 kn – 40 mph with wooden 15 x 6
5 m/s (960 ft/min) with wooden 15 x 6
12:30 with wooden 15 x 6
