8. Final setup & Painting/marking
Paint it to your favourite marking. You can use our scale PDF for make painting mask and easy
paint job.
Refer to your R/C system userguide for setup information.
Install your reciever, connect battery, setup servos and etc. with your trasmitter, check servo
position, then install propeller.
wing battery holder, if battery moves during flight it can shift the center of gravity backwards
and aircraft will become uncontrollable! Never set ESC with propeller installed, this could be
very dangerous!
you will need: Your own Rx/Tx system
See video guide Final Setting
aileron
9. Go flying
Pre-flight check center of gravity is very important
battery properly charged, ailerons and elevator deflection check, your own flying skills or RC
simulator training ...
Flight video of WACO YMF-5
... print your plane | www.3DLabPrint.com
Make sure the battery is positioned properly and secured with
elevator
+20 mm
-20 mm
page
rudder
+20 mm
-20 mm
(move it 5mm forward for the first flights),
23
50 mm L
50 mm R
