Shopping List - 3D LabPrint WACO YMF-5 User Manual

Shopping list

Printing material:
Motor:
ESC:
Propeller:
Battery:
Servos:
Glue:
Other:
... print your plane | www.3DLabPrint.com
2,5 kg of Polyair 1.0
a little piece of PETG for motor mount
any motor 5055 size for 6S Li-Pol with weight up to 450g
80A 6s with UBEC or any 6s 60-100A
+ conector suitable for battery
wooden 15 x 6 inch
2700-3700mAh/6s weight around 400-600g
4x Hitec HS-82MG or Corona CS-238MG
30x12x30mm (1.17 x 0.47 x 1.16 inches)
fresh!!!CA Glue medium viscosity
2x servo extension cables 300mm / 12 inch
2pcs of 10 mm carbon tube 780 mm (upper wing)
2pcs of 10 mm carbon tube 610 mm (bottom wing)
2pcs of 4mm carbon rod 316 mm
2pcs of 4mm carbon rod 270 mm
3x 1m of 1 - 1,2 mm / 14 AWG pushrod wire or carbon rod
6x M3x20 screws and nuts
6x M3x30 mm screws
20x 2x8 self screws
7x 3.5x15 self screws
page
+ activator
25
