General specifications:

Wingspan:
Lenght:
Height:
Wing area:
Wing loading:
Center of gravity:
Airfoil:
Print weight (LW PLA):
Empty weight (w/o battery):
Takeoff weight (3s 1300 lipo):
Max takeoff weight:
Never exceed speed, VNE:
Design maneuvering speed, VA:
Stall speed, VS:

Recommended setup

Motor: Leopard LC2830 980KV (for 3S setup)
ESC: Turnigy 20A / 3S
Propeller: two blade GWS 8 x 4 (ugly orange)
Battery: LiPol 1300mAh / 3s
printed PET motor mount

Performance measurement

Max speed VH (level flight):
Rate of climb:
Flight time (3s 1300mAh/full):
... print your plane | www.3DLabPrint.com
1068 mm / 42.0 inch
675 mm / 26.6 inch
310 mm / 12.2 inch
18,15 dm2 / 1.94 square feet
31 g/dm2 / 15.3 oz/square feet
44 mm / 1.73 inch from leading edge
LHK12 modified by 3DLabPrint
224 g / 7.90 oz
380 g / 13.40 oz
500 g / 17.63 oz
700 g / 24.70 oz
70 km/h / 50 mph
50 km/h / 31 mph
15 km/h / 9.4 mph
or similar
105 km/h – 56.7kn – 65.2mph with GWS 9x7,5
20 m/s (5 373 ft/min) with GWS 9x7,5
7:30 with GWS 8x4
