VL3600 PROFILE IP
Quick reFereNce dMX MaPS
The short form DMX maps are available on the following pages. Visit the product page for full DMX maps.
•
table 2. 16-Bit
•
table 3. 16-Bit enhanced Mode (default)
DMX
CHANNEL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
TAbLE 2.
PARAMETER
intensity High
intensity Low
Pan High
Pan Low
tilt High
tilt Low
Focus High
Focus Low
Zoom High
Zoom Low
cyan
Yellow
Magenta
ctO Wheel
color adjustment
(color Wheel 2)
color Wheel 1
color Wheel 1 control
Gobo Wheel 1 (Fixed)
Gobo Wheel 1 control
Gobo Wheel 2
Gobo Wheel 2 rotate/index
High Byte
Gobo Wheel 2 rotate/index
Low Byte
Gobo Wheel 2 control
VLFX (Gobo Wheel 3)
VLFX (Gobo Wheel 3)
rotate/index High Byte
16-bIT MODE
DMX
PARAMETER
CHANNEL
VLFX (Gobo Wheel 3)
26
rotate/index Low Byte
VLFX (Gobo Wheel 3)
27
control
28 iris
29 Frame 1a
30 Frame 1B
31 Frame 2a
32 Frame 2B
33 Frame 3a
34 Frame 3B
35 Frame 4a
36 Frame 4B
37 Frame rotate
38 Prism 1 (triangular)
Prism 1 index/rotate High
39
Byte
Prism 1 index/rotate Low
40
Byte
41 Prism 2 (Flat)
Prism 2 index/rotate
42
High Byte
Prism 2 index/rotate
43
Low Byte
44 Frost
45 Strobe
46 Future use channel
47 Programmers channel
48 Fan control
49 Luminaire control
8
Quick Start Guide
REV A 06/28/22
