NO:
73109
ISSUED:
DEC. 23, 1998
REVISED:
JAN. 13, 2004
HOSHIZAKI
CUBELET ICE DISPENSER
MODEL
DCM-230FE
SERVICE MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DCM-230FE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki DCM-230FE

Summary of Contents for Hoshizaki DCM-230FE

  • Page 1 73109 ISSUED: DEC. 23, 1998 REVISED: JAN. 13, 2004 HOSHIZAKI CUBELET ICE DISPENSER MODEL DCM-230FE SERVICE MANUAL...
  • Page 2 No service or maintenance should be undertaken until the technician has thoroughly read this Service Manual. HOSHIZAKI provides this manual primarily to assist qualified service technicians in the service and maintenance of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.

  • Page 3: Table Of Contents

    Please review this manual. It should be read carefully before the icemaker is serviced or maintenance operations are performed. Only qualified service technicians should service and maintain the icemaker. This manual should be made available to the tech- nician prior to service or maintenance. I.
  • Page 4 3. REMOVAL AND REPLACEMENT OF COMPRESSOR ... 42 4. REMOVAL AND REPLACEMENT OF DRIER ... 43 5. REMOVAL AND REPLACEMENT OF EXPANSION VALVE ... 44 6. REMOVAL AND REPLACEMENT OF ICE MAKING MECHANISM ... AND WATER SYSTEM ... 45 7. REMOVAL AND REPLACEMENT OF ELECTRICAL SYSTEM ... 51 8.

  • Page 5: General Information

    I. GENERAL INFORMATION 1. DIMENSIONS/CONNECTIONS...

  • Page 6: Construction

    2. CONSTRUCTION Hoshizaki Cubelet Ice Dispenser, model DCM-230FE includes Water Supply, Freezer, Condensing, Storage, Dispensing and Control Assemblies.

  • Page 7: Operation - How It Works

    3. OPERATION - How it works Water flows from the potable water source through the Water Supply Line Shut-off Valve, enters at the Water Inlet fitting and into the Water Reservoir. The Water Reservoir func- tions to maintain a constant water level inside the Freezer Assembly. Water from the Water Reservoir enters at the bottom of the Freezer.

  • Page 8: Timer Board

    4. TIMER BOARD [a] SOLID-STATE CONTROL 1) A HOSHIZAKI exclusive solid-state control is employed in the DCM-230FE cubelet ice dispenser. This control includes a microprocessor (LSI) developed by HOSHIZAKI. 2) A Printed Circuit Board (hereafter called “Timer Board”) includes a stable and high quality control system.

  • Page 10: [C] Sequence

    [c] SEQUENCE Bin Control Pressure Switch Ice Switch [portion controlled] Ice Switch [continuous] X1 Relay [Gear Motor] X2 Relay [Compressor Relay] X4 Relay [Agitating Motor] X5 Relay [Solenoid] [Dispensing Motor] r - i r - i n i t n i t...
  • Page 11 Functions of Relays 1) X1 - makes just when the Bin Control Circuit closes. - breaks t3 sec. after X2 breaks following the t2 sec. delay since the Bin Control Circuit opens. - will not make for t4 sec. after X2 breaks, even if the Bin Control Circuit closes. 2) X2 - makes t1 sec.

  • Page 12: Installation Instructions

    II. INSTALLATION INSTRUCTIONS The installation must be carried out by qualified personnel, in accordance with current regulations, according to the manufacturer’s instructions. 1. UNPACKING Children should not be allowed in reach of the packaging elements (plastic bags and expanded polystyrene) as they are potential sources of danger. 1.

  • Page 13: Location

    Upper Front Panel: Top Panel: Apron/Side Panel: 2. LOCATION 1. This ice dispenser is not intended for outdoor use. Normal operating ambi- ent temperature should be within +5°C to +40°C. Normal operating water temperature should be within +5°C to +35°C. Operation of the ice dispenser, for extended periods, outside of these normal temperature ranges may affect production capacity.

  • Page 14: Installation

    3. INSTALLATION • Incorrect installation can cause harm to people, animals or things, for which the manufac- turer cannot be held responsible. 1) Position the ice dispenser in the selected permanent site. 2) Level the ice dispenser in both the left-to-right and front-to-rear directions. 4.

  • Page 15: Water Supply And Drain Connections

    The correct replacement for the detachable fuse cover is identifiable from the manufacturer’s reference number stamped on the plug. Supply of replacement fuse covers can be obtained from Hoshizaki Parts/Service Centres. Fuses should be rated at 10A and approved to BS 1362.
  • Page 16 4) Attach grey flexible outlet hoses (accessory) to the R3/4 fittings on the rear bottom of the ice dispenser, confirming fitment of rubber washers before finally hand tightening the joints. These pipes can be cut to length as necessary to suit position of main drain. Fig.

  • Page 17: Operating Instructions

    III. OPERATING INSTRUCTIONS 1. This ice dispenser is designed to produce and store edible ice. To keep the ice dispenser hygienic: • Wash your hands before removing ice. • Keep the Grille in the Tray clean. Clean it by using a neutral cleaner and rinse thoroughly.
  • Page 18 Be sure that the Control Switch, located at the bottom of the Middle Front Panel, is moved to the “ICE” position. Verify that the Manual Drain Valve at the bottom right of the Middle Front Panel is closed. 6) Replace the Front Panel in its correct position. 7) Check that water flows into the Water Supply and the Freezer Assembly: •...

  • Page 19: Controls And Adjustments

    2. CONTROLS AND ADJUSTMENTS - Portion Control • The Portion Control is located on the Control Box to control the amount of ice dispensed. If adjustment is desired, please contact an authorized Hoshizaki service company. • The numbers on the label indicate dispensing time (sec.).
  • Page 20 1) Close the Water Supply Line Shut-off Valve. 2) Move the Change Switch, located on the bottom of the Middle Front Panel, to the “CONTINUOUS” position. 3) Press the Push Button to dispense ice, and remove all ice from the Storage Bin. 4) Open the Drain Valve at the bottom of the Middle Front Panel.

  • Page 21: Maintenance

    IV. MAINTENANCE Ensure all components, fasteners and thumbscrews are securely in place after any maintenance or cleaning is done to the equipment. 1. Before carrying out any cleaning or maintenance operations, unplug the ice dispenser from the electrical supply network. 2.

  • Page 22: Cleaning Of Water System

    2. CLEANING OF WATER SYSTEM 1. Clean and sanitize the ice dispenser Water System at least twice a year, by using a recommended cleaner and sanitizer. 2. To prevent injury to individuals, do not use any ammonia type cleaners. 3. Always wear liquid-proof gloves for safe handling of the cleaning and sanitizing solution, to prevent irritation in case of contact with skin.
  • Page 23 11) Pour water into the Reservoir to rinse the cleaning solution, and drain the water system. See 6) and 7). 12) Dilute approximately 0.03 lit. of a 5.25% Sodium Hypochlorite Solution with 6 lit. of water. 13) Pour the sanitizing solution into the Reservoir. Be careful not to overfill. 14) Wait for 10 minutes before starting the icemaking process.
  • Page 24 3) Remove the Bin Control Bracket Assembly. See Fig. 10. 4) Remove the Snap Pin, the Shaft and the Activator. 5) Remove the thumbscrews, the Spout and the Packing. See Fig 11. Fig. 10 Fig. 11 6) Remove the Spout Cover, black Ice Dispensing Spout and Water Dispensing Nozzle. See Fig.
  • Page 25 7) Immerse the Agitator, Dispensing Auger, Bin Control Bracket Assembly, Spout, Packing, Spout Cover, black Ice Dispensing Spout and Water Dispensing Nozzle in the cleaning and sanitizing solutions for about 15 minutes respectively. 8) Rinse these parts thoroughly with clean water. 9) Wipe thoroughly the Shutter located above the Ice Dispensing Spout.
  • Page 26 9) Plug in the ice dispenser. 10) Check for water leaks. 11) Replace the panels in their correct positions. Fig. 13...

  • Page 27: Technical Information

    V. TECHNICAL INFORMATION 1. WATER CIRCUIT AND REFRIGERANT CIRCUIT...

  • Page 28: Wiring Diagram

    2. WIRING DIAGRAM...

  • Page 29: Timing Chart

    3. TIMING CHART...

  • Page 30: Specifications

    4. SPECIFICATIONS DCM-230FE-UK AC SUPPLY VOLTAGE AMPERAGE STARTING AMPERAGE ELECTRIC CONSUMPTION POWER FACTOR ELECTRIC CAPACITY APPROXIMATE ICE PRODUCTION PER 24 HR. SHAPE OF ICE ICE QUALITY APPROXIMATE STORAGE CAPACITY WATER CONSUMPTION PER 24 HR. EXTERIOR DIMENSIONS (WxDxH) EXTERIOR FINISH WEIGHT...

  • Page 31: Performance Data

    5. PERFORMANCE DATA...

  • Page 32: Ice Dispensing Capacity

    6. ICE DISPENSING CAPACITY Ice Production: 190 kg/day Ambient Temperature: 20°C Maximum Continuous Dispensing Capacity With Full Ice Storage (11 kg) 366* Time (min.) * = Storage Capacity (11000g) / Dispensing Amount Per Cup (30g) ** = {Storage Capacity (11000g) + Ice Production Per Hour (7917g)} / Dispensing Amount Per Cup (30g) *** = 3600 sec.
  • Page 33 Ice Production: 210 kg/day Ambient Temperature: 20°C Maximum Continuous Dispensing Capacity With Full Ice Storage (11 kg) 366* Time (min.) * = Storage Capacity (11000g) / Dispensing Amount Per Cup (30g) ** = {Storage Capacity (11000g) + Ice Production Per Hour (8750g)} / Dispensing Amount Per Cup (30g) *** = 3600 sec.
  • Page 34 Ice Production: 150 kg/day Ambient Temperature: 30°C Maximum Continuous Dispensing Capacity With Full Ice Storage (11 kg) 366* Time (min.) * = Storage Capacity (11000g) / Dispensing Amount Per Cup (30g) ** = {Storage Capacity (11000g) + Ice Production Per Hour (6250g)} / Dispensing Amount Per Cup (30g) *** = 3600 sec.
  • Page 35 Ice Production: 170 kg/day Ambient Temperature: 30°C Maximum Continuous Dispensing Capacity With Full Ice Storage (11 kg) 366* Time (min.) * = Storage Capacity (11000g) / Dispensing Amount Per Cup (30g) ** = {Storage Capacity (11000g) + Ice Production Per Hour (7083g)} / Dispensing Amount Per Cup (30g) *** = 3600 sec.

  • Page 36: Service Diagnosis

    VI. SERVICE DIAGNOSIS PROBLEM [1] The ice dispenser a) Power Supply will not start. b) Power Switch (Control Box) c) Fuse (Control Box) [2] Ice dispensing a) Water Control Relay operates, but no ice is produced. b) Pressure Switch c) Compressor [3] Water Valve a) Water Supply Line operates, but no ice...
  • Page 37 PROBLEM b) Overload Protector c) Starter d) Starting or Running Capacitor e) X2 Relay on Timer Board Compressor g) Fan Motor [5] Poor ice production a) Condenser capacity. b) Expansion Valve c) Refrigerant Lines d) Installation Site e) Inside Wall of Evaporator Water Supply POSSIBLE CAUSE...
  • Page 38 PROBLEM Dispenser will not a) Bin Control stop even if Bin is filled with ice. Fan Motor will not a) Fan Motor start, or is not operating. b) X2 Relay on Timer Board Gear Motor (Ice a) Gear Motor Making) is not operating.
  • Page 39 PROBLEM c) Float Switch d) Water Control Relay [12] No water or poor a) Water Supply flow. b) Water Valve c) Float Switch d) Water Control Relay [13] Much water drains a) Mechanical Seal from Evaporator (normally less than bottom. 0.5 ml/h) b) O-ring [14] No ice is...

  • Page 40: Removal And Replacement Of Components

    VII. REMOVAL AND REPLACEMENT OF COMPONENTS Ensure all components, fasteners and thumbscrews are securely in place after the equipment is serviced. 1. The Polyolester (POE) oils used in R-404A units can absorb moisture quickly. Therefore it is important to prevent moisture from entering the system when replacing or servicing parts.

  • Page 41: Brazing

    5) Disconnect the Vacuum Pump, and attach a Refrigerant Service Cylinder to the High-side line. Remember to loosen the connection, and purge the air from the Hose. See the Nameplate for the required refrigerant charge. Hoshizaki recommends only virgin refrigerant or reclaimed refrigerant which meets ARI Standard No. 700-88 be used.

  • Page 42: Removal And Replacement Of Compressor

    3. REMOVAL AND REPLACEMENT OF COMPRESSOR Always install a new Drier every time the sealed refrigeration system is opened. Do not replace the Drier until after all other repair or replacement has been made. 1) Unplug the ice dispenser. 2) Remove the panels. 3) Remove the Terminal Cover on the Compressor, and disconnect the Compressor Wir- ing.

  • Page 43: Removal And Replacement Of Drier

    16) Evacuate the system, and charge it with refrigerant. See the Nameplate for the required refrigerant charge. 15) Connect the Terminals to the Compressor, and replace the Terminal Cover in its correct position. 17) Replace the panels in their correct positions. 18) Plug in the ice dispenser.

  • Page 44: Removal And Replacement Of Expansion Valve

    5. REMOVAL AND REPLACEMENT OF EXPANSION VALVE Sometimes moisture in the refrigerant circuit exceeds the Drier capacity and freezes up at the Expansion Valve. Always install a new Drier every time the sealed refrigeration system is opened. Do not replace the Drier until after all other repair or replacement has been made.

  • Page 45: Removal And Replacement Of Ice Making Mechanism And Water System

    6. REMOVAL AND REPLACEMENT OF ICE MAKING MECHANISM AND WATER SYSTEM [a] GEAR MOTOR AND BEARING - LOWER 1) Unplug the ice dispenser. 2) Close the water supply tap. 3) Remove the panels. 4) Open the Drain Valve by rotating the knob, and after draining water, close the Drain Valve. 5) Remove the Auger.
  • Page 46 Fig. 14...
  • Page 47 10) Install the new Gear Motor. Insert the liner under the Gear Motor, and secure it with the three hexagon bolts. 11) Assemble the removed parts in the reverse order of which they were removed. 12) Open the water supply tap. 13) Plug in the ice dispenser.
  • Page 48 10) Replace the Cutter, Cylinder Packing, Spouts, Packing and panels in their correct position. 11) Open the water supply tap. 12) Plug in the ice dispenser. 13) Check for water leaks. After assembling the Extruding Head, be sure to check that the Auger does not contact with the inner surface of the Evaporator and there is not any ab- normal noise from the Bearing.
  • Page 49 4) Remove the Floating Seat portion of the Mechanical Seal from the Bearing - Lower. 5) Install the new Mechanical Seal. 1. When installing the Mechanical Seal (Bellows portion) onto the Auger, it should be perpendicular to the Auger. Be sure no dirt or foreign matter adheres to the contact surface of the Seal Ring.
  • Page 50 10) Check for water leaks. 11) Replace the panels in their correct position. [f] FLOAT SWITCH 1. Fragile, handle very carefully. 2. If the Float Switch works poorly because of scale or other foreign matter, install a filter or softener in the water supply line. 1) Unplug the ice dispenser.

  • Page 51: Removal And Replacement Of Electrical System

    7. REMOVAL AND REPLACEMENT OF ELECTRICAL SYSTEM [a] BIN CONTROL (PROXIMITY SWITCH) 1) Unplug the ice dispenser. 2) Remove the Front Panel and Top Panel. Note: The Proximity Switch is located on the outside of the Bin Top Panel. 3) Cut the leads at the wire connectors. 4) Remove the Switch Cover and the Proximity Switch.
  • Page 52 7) Connect the terminals. 8) Assemble the removed parts in the reverse order of which they were removed. 9) Plug in the ice dispenser. [c] ELECTRICAL COMPONENTS The following table shows the location of the electrical components. Be sure to unplug the ice dispenser before replacing the components.

  • Page 53: Removal And Replacement Of Dispensing System

    8. REMOVAL AND REPLACEMENT OF DISPENSING SYSTEM [a] AGITATOR 1) Unplug the ice dispenser. 2) Remove the Front Panel. 3) Remove the Bin Front Panel. 4) Remove the Thumbscrews and pull off the Gear Motor Bracket. Note: Hold the Agitator not to drop it when pulling off the Gear Motor Bracket. 5) Replace the Agitator with the new one.

  • Page 54: Before Calling A Service Agent

    For further assistance or advice, contact your local Hoshizaki service agent. 10. WARRANTY Hoshizaki warrants to the original owner/user that all Hoshizaki branded products shall be free of defects in material and/or workmanship for the duration of the “warranty period”. The warranty shall be effective for two years from the date of installation in EU countries, but only one year in other countries.
