- Page 1 OPEN OPTIONS ® A C C E S S T E C H N O L O G Y ZKTeco Quick Start Guide...
- Page 3 This manual is proprietary information of Open Options, LLC. Unauthorized reproduction or distribution of this manual is strictly forbidden without the written consent of Open Options, LLC. The information contained in this manual is for informational purposes only and is subject to change at any time without notice.
- Page 4 Open Options Software License Agreement THE ENCLOSED SOFTWARE PACKAGE IS LICENSED BY OPEN OPTIONS, LLC. TO CUSTOMERS FOR THEIR NON-EXCLUSIVE USE ON A COMPUTER SYSTEM PER THE TERMS SET FORTH BELOW. DEFINITIONS: Open Options shall mean Open Options, LLC, which has the legal right to license the computer application known as DNA Fusion herein known as the Software.
-
Page 5: Installation
Step 1: Wiring the ZKTeco SF1005-V+ - Wire the Power In cables to power the device. For access controller communication, wire the Wiegand Out cables to the DAT / CLK (D1 / D0) terminal of the SSP controller. -
Page 6: Installation Environment
ZKTeco SF1005-V+: Quick Start Guide Installation Environment Follow these recommendations for the physical installation of the reader. ● Install Indoors ● Avoid Glass Refraction ● Avoid Direct Sunlight and Exposure ● Keep Away from Heat Source ● Effective Distance for Palm Scans: 30-50cm ●... - Page 7 Wiring the ZKTeco SF1005-V+ Follow the steps below to wire the ZKTeco SF1005-V+. NOTE: The industry wiring colors do NOT apply to the ZKTeco SF1005-V+ wiring harness. Wire the Power In (12V / GND) terminals to power the device. To establish communication between the SF1005-V+ to the controller/sub-controller, wire Wiegand Out terminals to the DAT D0 / CLK D1 (Reader Port 1 or 2) terminals on the controller/subcontroller.
-
Page 8: Additional Wiring
ZKTeco SF1005-V+: Quick Start Guide Additional Wiring To wire any additional features to the SF1005-V+, see the diagrams below. ZKTeco SF1005-V+ Wire Terminals Exit Buttons, Sensors, and Alarm Connection Page 4 Open Options Confidential... - Page 9 ZKTeco SF1005-V+ : Quick Start Guide Lock Relay Connection RS485 and RS232 Connection Open Options Confidential Page 5...
- Page 10 ZKTeco SF1005-V+: Quick Start Guide This Page Intentionally Left Blank Page 6 Open Options Confidential...
-
Page 11: Adding A New User
ZKTeco SF1005-V+ : Quick Start Guide Adding a New User Once the SF1005-V+ is wired and powered, begin adding users to the device. See the following steps for instructions on adding users. On the SF1005-V+, select the Main Menu icon Keyboard icon. - Page 12 ZKTeco SF1005-V+: Quick Start Guide User Credential Enrollment Each New User is assigned with a User ID. Selecting User ID will allow the user to change the ID number. Users have the option of setting up various biometric verifications to register to the reader. Setting the Badge Number verification is required to link DNA Fusion with the SF1005-V+.
- Page 13 ZKTeco SF1005-V+ : Quick Start Guide Select Name and enter the user’s name. Select User Role and select a Role. The user can be added as a Normal User or a Super Admin. If needed, add the Palm verification. a. Select Palm.
- Page 14 ZKTeco SF1005-V+: Quick Start Guide If needed, add a Face verification. a. Select Face. b. Present the new user’s face to the SF1005-V+. c. Follow the directions on the Enroll Face screen. The user’s face will be registered once the progress bar at the bottom spans from one side of the screen to the other.
-
Page 15: Additional Parameters
ZKTeco SF1005-V+ : Quick Start Guide Adding Verification Method The SF1005-V+ allows the user to use multiple verification methods or combine verification methods. In the Main Menu, select Access Control > Access Control Options > Verification Mode. Select an option shown on the screen. - Page 16 ZKTeco SF1005-V+: Quick Start Guide If needed, select Enable temperature screening with infrared. Enabling temperature screening allows for monitoring of the user’s body temperature. If needed, select Enable mask detection. Page 12 Open Options Confidential...
- Page 17 ZKTeco SF1005-V+ : Quick Start Guide Adding the ZKTeco SF1005-V+ to DNAFusion To add the SF1005-V+ to DNA Fusion, expand the SIO tree (either an SSP On-board or a seperate SIO) and add the SF1005-V+ as a reader. A profile must also be created in DNA Fusion before the user can gain access to the door.
- Page 18 16650 Westgrove Dr | Suite 150 Addison, TX 75001 Phone: (972) 818-7001 Publish Date | August 25, 2020 DNA Fusion Version | 7.8.0.5 Manual Number | ZQSG 1.0 www.ooaccess.com...
