Ruijie RG-NBS3200 Series Switches Hardware Installation and Reference Guide
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 1.5A
Input Leakage
≤3.5mA
Current
Supported
EEE
PoE Not supported
Power
28W
Consumption
Operating temperature: 0 º C to 50º C
Temperature
Storage temperature: -40 º C to 70º C
Operating humidity: 10% to 90% RH
Humidity
Storage humidity: 5% to 95% RH
Fan Supports adaptive speed adjustment
Temperature
Not supported
Alarm
GB9254-2008
EN 55032:2015+AC:2016
EN 61000-3-2:2014
EMC Standards
EN 61000-3-3:2013
EN 55035:2017
ETSI EN 300 386 V2.1.1 (2016-07)
Security GB4943-2011
EN 62638-1
Standards
Dimensions
440 mm x 207.5 mm x 43.6 mm (with front panel )
(W x D x H)
Weight 2.9 kg
The RG-NBS3200-24GT4XS switch is a class A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
Product Appearance
On the front panel, the RG-NBS3200-24GT4XS Ethernet switch provides 24 10/100/1000Base-T Ethernet ports and 4
SFP+ ports. On the back panel, it provides an AC power port.
Figure 1-1 Appearance of RG-NBS3200-24GT4XS
Product Overview
