Item
MIRROR
STANDBY MODE

MONITOR OUT

Using the ▲/▼ cursor buttons switches the mode for mirror status.
NORMAL
H:INVERT
If the Transition Detector is on and the MIRROR status is changed,
the TRANSITION DETECTOR ON alarm (
when projector is restarted after the AC power is turned off.
Using ▲/▼ cursor buttons switches the standby mode setting
between the NORMAL and the SAVING.
NORMAL
SAVING
• When the SAVING is selected and the projector is in the standby
state, the power consumption is lowered with some functional
restriction as below.
- The RS-232C communication control is disabled except turning
the projector on and changing the STANDBY MODE setting.
- The STANDBY of the MONITOR OUT (
signal is output from the MONITOR OUT port.
- The AUDIO OUT STANDBY of the AUDIO SOURCE (
invalid, and no signal is output from the AUDIO OUT ports (
• If the COMMUNICATION TYPE in the COMMUNICATION menu
is set to NETWORK BRIDGE, all of the RS-232C commands are
52).
disabled (
The combination of a picture shown on screen and output from the
MONITOR OUT port can be arranged in the menu.
The picture coming into the port selected in the (2) is output to the
MONITOR OUT port while an image from the port chosen in the (1)
is on screen.
(1) Choose a picture input port using
▲/▼ cursor buttons.
• Select STANDBY to specify the
output from the MONITOR OUT port
in the standby state. This selection is
available only when NORMAL is selected for the STANDBY MODE
above
(
).
(2) Select one of the COMPUTER IN ports using the ◄/► cursor
buttons.
Choosing the COMPUTER IN1 allows the following choice.
COMPUTER IN1
Choosing the COMPUTER IN2 allows the following choice.
COMPUTER IN2
Choosing other input or the STANDBY allows the following choice.
COMPUTER IN1
• The OFF disables the MONITOR OUT port.
Description
V:INVERT
H&V:INVERT
below
OFF
OFF
COMPUTER IN2
SETUP menu
63) will be displayed
) is invalid, and no
40) is
18).
OFF
39
