PICTURE menu
Item
COLOR TEMP
COLOR
(continued on next page)
30
Using the ▲/▼ cursor buttons switches the color temperature mode.
1 HIGH
6 CUSTOM
6 Hi-BRIGHT-3
5 CUSTOM 5 Hi-BRIGHT-2
To adjust CUSTOM
Selecting a mode whose name
includes the CUSTOM and then
pressing the ► cursor (or the ENTER)
button displays a dialog to aid you in
adjusting the OFFSET and GAIN of the
selected mode.
The OFFSET adjustments change the color intensity on the whole
tones of the test pattern.
GAIN adjustments mainly affect color intensity on the brighter tones
of the test pattern.
Choose an item using the ◄/► cursor buttons, and adjust the level
using the ▲/▼ cursor buttons.
You can display a test pattern for checking the effect of your
adjustment by pressing the ENTER (or the INPUT) button.
Each time you press the ENTER (or the INPUT) button, the pattern
changes as below.
No pattern Gray scale of 9 steps
Ramp
• Lines or other noise might appear on the screen
when this function is operated, but it is not a
malfunction.
Using the ◄/► cursor buttons adjusts the strength of whole color.
Weak Strong
• This item can be selected when input signals are video, s-video or
component video signals.
• When input signal is HDMI, this item can also be selected if either 1)
or 2) applies.
1) HDMI FORMAT is set to VIDEO.
2) HDMI FORMAT is set to AUTO, and the projector recognizes that
it receives video signals.
Description
1 CUSTOM 2 MID
4 CUSTOM
Gray scale of 15 steps
2 CUSTOM
3 LOW
3 CUSTOM
4 Hi-BRIGHT-1
