Emtek CF 2.0 Installation Manual page 4

6. Install the Trims cont.
Step 6C: Slide the door lever or knob onto the spindle.
Step 6D: Firmly tighten the Pre-installed set screw in the lever or knob with the provided Hex Torque
wrench. Ensure that it is firmly tightened.
Step 6E: Repeat steps 6A-6D for opposite side. For Privacy Lock, screw the Privacy Pin through the rosette, into the
latch. To check functionality, turn the interior lever/knob to engage the latch. Now, push the privacy pin in and turn the
exterior lever/knob. The exterior lever/knob should not retract the latch.
!
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause
cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.
4
!
Set screw location varies
by knob/lever.
Tighten set screw using provided hex torque
!
wrench until wrench touches the plastic
indicator as shown.
Emergency Release
! For emergency, insert Emergency Release Tool
into the release hole of the exterior rosette to
open the lock.
!
