DEMO MANUAL DC2522A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 1 C2
2 1 C4
3 1 C5
4 1 C6
5 1 C8
6 1 L1
7 1 R2
8 1 R3
9 2 R1, R4
10 1 R5
11 1 U1
Additional Demo Board Circuit Components
1 1 C1
2 2 C3, C10
3 1 C9
4 1 C11
5 1 C12
6 1 FB1
7 1 L2
8 0 R6 (OPT)
Hardware: For Demo Board Only
1 9 E1 TO E9
2 1 E10 (OPT)
3 1 JP1
4 1 XJP1
5 4 MH1 TO MH4
6
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP , X7R, 4.7µF, 50V, 10% 1206
CAP , X7R, 1µF, 25V, 10%, 0603
CAP , C0G, 10pF, 25V, 5%, 0603
CAP , X7R, 47µF, 10V, 10%, 1210
CAP , X7R, 0.01µF, 16V, 10%, 0603
IND, 2.2µH
RES, CHIP , 18.2k, 1/10W, 1%, 0603
RES, CHIP , 49.9k, 1/10W, 1%, 0603
RES, CHIP , 1M, 1/10W, 1%, 0603
RES, CHIP , 182k, 1/10W, 1%, 0603
IC, REGULATOR, LQFN-16
CAP , ALUM 22µF 63V
CAP , X7R, 4.7µF, 50V, 10% 1206
CAP , X7R, 4.7µF, 16V, 10%, 0805
CAP , X7R, 1µF, 50V, 10%, 0805
CAP , X7R, 0.1µF, 50V, 10%, 0603
FERRITE BEAD 0805
RES, CHIP , 0Ω, 3/4W, 2010
RES, 0603
TESTPOINT, TURRET, 0.094"
TESTPOINT, TURRET, 0.094"
DOUBLE ROW HEADER 2 × 4 0.079"
SHUNT, 0.079" CENTER
STAND-OFF , NYLON 0.50" TALL
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475KA12L
MURATA, GRM188R71E105KA12D
AVX, 06033A100JAT2A
MURATA, GRM32ER71A476KE15L
AVX, 0603YC103KAT2A
COILCRAFT, XFL4020-222ME
VISHAY, CRCW060318K2FKEA
VISHAY, CRCW060349K9FKEA
VISHAY, CRCW06031M00FKEA
VISHAY, CRCW0603182KFKEA
LINEAR TECHNOLOGY, LT8609SEV#PBF
SUN ELECT, 63CE22BS
MURATA, GRM31CR71H475KA12L
MURATA, GRM21BR71C475K73L
MURATA, GRM21BR71H105KA12L
MURATA, GRM188R71H104KA93D
TDK, MPZ2012S331AT000
VISHAY, CRCW20100000Z0EF
MILL-MAX, 2501-2-00-80-00-00-07-0
SULLINS, NRPN042PAEN-RC
SAMTEC, 2SN-BK-G
KEYSTONE, 8833(SNAP ON)
dc2522af
