SAMCHULLY NC Rotary Table Series Instruction Manual page 5

TABLE OF CONTENTS
For Safe Operation
1.
Specifications
2.
Accuracy
3.
Preparations for Operation
4.
4-1. Installation
4.1.1. Transportation, and Installation on the Machine Tool
4-2. Lubrication
4.2.1. Recommended Volume
4.2.2. Recommended Lubricant
4-3. Clamp System
4.3.1. Air Clamp System
4-4. About the Air Purge System
4-5. Mounting a Workpiece
Inspection
5.
5-1. Daily Inspection
5-2. Periodic Inspection
Description of the NC Rotary Table
6.
6-1. Cautions for the Table Clamp
6-2. Clamp, Unclamp Check Device
6-3. Solenoid Valve for Clamp, Unclamp
7. Description, maintenance
and adjustment of components
7-1. Adjusting backlash of worm gear
7.1.1. Method of Measuring Worm Gear Backlash
7.1.2. How to Adjust the Backlash of the Worm gear
7.1.3. How to Adjust the Backlash of the Worm gear
7-2. Removal and installation of cover for replacing the motor
7.2.1. Removing the motor cover
7.2.2. Waterproofing Measures
Storage
8.
References
9.
9-1. Conversion between Arc Length and Angle
(Before 2018.1.)
(After 2018.1.)
6
13
14
15
15
15
16
16
16
17
17
18
18
19
19
19
19
19
20
20
21
21
21
22
22-1
24
24
24
25
26
26
