x-IMU3 User Manual v0.11
April 6, 2022

11.1.35 Wi-Fi client key

Description: Configures the security key in Wi-Fi client mode. This is the password for the router
that the device will connect to. If the router does not require a password then this
setting will be ignored. The key may be up to 31 characters long.
JSON key:
"wiFiClientKey"
JSON value type: string
Default value: "xiotechnologies"

11.1.36 Wi-Fi client channel

Description: Configures the channel in Wi-Fi client mode. This is the channel of the router that
the device will connect to. Setting the correct channel will decrease the time taken
to connect. If the channel is incorrect then the device will search all channels and
then update this setting for the correct channel. The possible channels are listed in
Table 32.
JSON key:
"wiFiClientChannel"
JSON value type: number
Default value: 0

11.1.37 Wi-Fi client DHCP enabled

Description: Enables (true) or disables (false) Dynamic Host Configuration Protocol (DHCP) in
Wi-Fi client mode. If DHCP is enabled then the device will be assigned an IP address
by the router. This is an automatic process and the recommend mode of operation.
If DHCP is disabled then the IP address, netmask, and gateway must be configured
by the user.
JSON key:
"wiFiClientDhcpEnabled"
JSON value type: true or false
Default value: true
Channel
0
1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11
12, 13
14
36, 40, 44, 48
52, 56, 60, 64, 100, 104, 108, 112, 116
120, 124, 128
132, 136, 140
149, 153, 157, 161, 165
Table 32: Wi-Fi client channels
Band Notes
- All channels
2.4 GHz -
2.4 GHz Invalid for US
2.4 GHz Invalid for US and EU
5 GHz -
5 GHz, DFS -
5 GHz, DFS Invalid for US
5 GHz, DFS -
5 GHz Invalid for EU and JP
