Power; Inner Row Connectors - Texas Instruments SimpleLink CC3100 User Manual

Hardware Description
Pin No Signal Name
P3.1
P3.2
P3.3 UNUSED
P3.4 UNUSED
P3.5 UNUSED
P3.6 UNUSED
P3.7 UNUSED
P3.8 UNUSED
P3.9 UNUSED
P3.10 UNUSED
NOTE: All signals are 3.3 V CMOS 400mA logic levels and are referred w.r.t. CC3100 IC. For
example, UART1_TX is an output from the CC3100.
For the SPI lines, the CC3100 always acts like a slave.
2.4

Power

The board is designed to accept power from a connected LaunchPad or from the CC3100EMUBOOST
board. Some of the LaunchPads are not capable of sourcing the peak current requirements of Wi-Fi. In
such a case, the USB connector on the CC3100BOOST can be used to aid the peak current. The use of
Schottky diodes ensure that the load sharing happens between the USB connectors on the LaunchPad
and the BoosterPack without any board modifications.
Also the 3.3 V power can be sourced from the LaunchPad or from the 3.3 V LDO on the board. This is
done by using jumper J8. In the case where the LaunchPad is not able to source the 3.3 V up to 350mA,
then the J8 needs to be configured to work from the on-board LDO.
10
CC3100 SimpleLink™ Wi-Fi
Table 5. Inner Row Connectors
Direction
+5 V IN
GND IN
NA
NA
NA
NA
NA
NA
NA
NA
® and IoT Solution BoosterPack Hardware
Copyright © 2014–2015, Texas Instruments Incorporated
Pin No Signal Name
P4.1 UNUSED
P4.2 UNUSED
P4.3 UNUSED
P4.4 UART1_CTS
P4.5 UART1_RTS
P4.6 UNUSED
P4.7 NWP_LOG_TX
P4.8 WLAN_LOG_TX
P4.9 UNUSED
P4.10 UNUSED
SWRU371B – June 2014 – Revised January 2015
Submit Documentation Feedback
www.ti.com
Direction
OUT
OUT
NA
IN
OUT
NA
OUT
OUT
IN
OUT
