- Page 1 WayPoint102 DC Outdoor Power Supply/Charger Installation Guide More than just power. Rev. 083018...
-
Page 2: Specifications
Overview: Altronix WayPoint102 DC Outdoor Power Supply/Charger provides 12VDC and is designed to be conveniently located where power is required. Specifications: Input: Visual Indicators: • Input: 120VAC, 60Hz, 3.5A. • Green AC Power LED indicates 120VAC present. • Input fuse rating: 5A/250V. - Page 3 A removed battery is reported within 5 minutes. Battery reconnection is reported within 1 minute (power-limited) (Fig. 1b, pg. 4). Stand-by battery connections. Maximum charge current 1.54A (non power-limited) – BAT + (Fig. 1g, pg. 4). WayPoint102 - 3 -...
- Page 4 BAT FAIL AC FAIL AC DELAY SHUTDOWN 1 min. enable TRIGGER EOL NC C NO NC C NO + AUX – 2 hr. disable SUPERVISED RESET Fig. 2 Suggested Locations for Wiring Inlets Bottom of Enclosure - 4 - WayPoint102...
- Page 5 Fig. 3 - WayPoint102 AC FAIL BAT FAIL AC DELAY SHUTDOWN 5A 250V 1 min. enable TRIGGER EOL NC C NO NC C NO + AUX – 2 hr. disable SUPERVISED RESET CAUTION HIGH VOLTAGE The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within the product’s enclosure that may...
- Page 6 Notes: - 6 - WayPoint102...
-
Page 7: Wall Mount Installation
This installation should be made by qualified service personnel. This product contains no serviceable parts. PMK1 is intended for use with Altronix outdoor rated power supplies or accessories housed in WP1, WP2, WP3 and WP4 enclosures. Brackets are designed for use with the Wormgear Quick Release Straps (two included). - Page 8 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIWayPoint102...
