Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.
Surge Protection
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and
secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LIGHTING
Installation and Maintenance
Instructions
Bollard
CFY259 LED
ZFY230 LED
KTY234 LED
KTX234 LED
INSTALLER
HOTLINE
+61 458 933 399
7am – 7pm AEST
Advertisement
Related Manuals for WE-EF KTY234 LED
Summary of Contents for WE-EF KTY234 LED
- Page 1 WE-EF LIGHTING Installation and Maintenance Instructions Bollard CFY259 LED ZFY230 LED KTY234 LED KTX234 LED INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST Do not open during installation Surge Protection This product is factory-sealed. For comprehensive protection of a luminaire installation against lightning and...
- Page 3 Bollard ZFY230 ZFY230 H = 600 mm H = 1000 mm ø 180 ø 180 1000 IP66, Class I (Class II, III available on request), ta = 25°C Weight for ZFY230 for ZFY230 1000 Accessories: Planted root – Galvanised steel. ESV4 for ZFY230 300-0461...
- Page 4 Bollard KTX234 KTY234 KTY234 H = 270 mm H = 600 mm H = 1000 mm ø 180 IP66, Class I (Class II, III available on request), ta = 25°C Weight for KTX234 for KTY234 for KTY234 1000 Accessories: Planted root – Galvanised steel. ESV4 for KTY234 300-0461...
- Page 5 Bollard CFY259 CFY259 H = 685 mm H = 1085 mm ø 240 ø 240 1085 CFY259 CFY259 H600 / 6 LED H1000 / 2x6 LED 65° ø 190 ø 240 IP66, Class I, (Class II, III available on request) ta = 25°C Weight WARNING : HEAVY ITEMS for CFY259...
-
Page 6: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. To remove the head of the luminaire during maintenance, loosen screw X with a Torx T-20 tool and rotate anti-clockwise until it can be lifted up. - Page 7 In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open the luminaire or remove the bollard head while mains supply is switched on. The luminaire head unit B is factory sealed, warranty will be void if opened without authorisation from WE-EF Lighting or nominated agent.
-
Page 8: Installation Procedure
D (base is integrated If the supplied cable of the KTX luminaire is damaged, on KTX). Note that the rear of the bollard is where it must be replaced by WE-EF or a WE-EF authorized the head retention screw X is positioned. agent. - Page 9 Torque: Screw Torque max. 2.0 Nm Fig. 2 max. 4.0 Nm max. 6.0 Nm max. 15.0 Nm max. 100.0 Nm Fig. 3 Fig. 1...
