WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Post Mounted Luminaires
AFL100 series
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained
in this document for details.
Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operating high-power devices such as, for example, electrical
arc welders.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for WE-EF AFL100 Series
Summary of Contents for WE-EF AFL100 Series
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Post Mounted Luminaires AFL100 series Do not open during installation This product is factory-sealed. Refer to the instructions contained in this document for details. Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards.
-
Page 2: Tool Required
Post Mounted Luminaires AFL120 ø 89 191.5 AFL130 ø 89 191.5 IP66. IK08 [AFL120], IK09 [AFL130]. Class I, II. T a = 25°C ø 9 – 14 mm 1 – 2.5 mm Tool required Torx 20, 45 5 mm Allen key Weight Windage area for AFL120... -
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out by a suitably qualified and trained professional. Warning: Do not open luminaire while mains supply is switched on. - Page 4 Post top and Side entry Attachment M can be mounted vertically or horizontally. To change position loosen fasteners J, rotate by 180° and refasten. For vertical mounting, attachment can be set at 0° or 2.5° by loosening screws J. For horizontal mounting, attachment can be set at 0°, 2.5°, 5°, 7.5°, 10°, 12.5°, and 15°.
-
Page 5: Installation Procedure
Installation Procedure Switch off and isolate mains electrical supply. 2) Pull the connecting cable through the pole. Place the luminaire on top of the pole and tighten fasteners B, tightening to a torque of 10 Nm. 10 Nm ø 40-60 x 100* ø... - Page 6 Trim mains cable E to the desired length and connect the leads to their respective terminals at the base of the pole: ON/OFF (L = Phase, N = Neutral, = Earthing) BASIC (L1 = Phase 1, L2 = Phase 2,N = Neutral, = Earthing) DALI (L = Phase, N = Neutral, = Earthing, DA/DA = DALI control line)
- Page 7 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9280W0223 © WE-EF 2023 Technical specifications are subject to change.
