Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollard
XRY324 LED
XRY334 LED
RRY324 LED
RRY334 LED
XRZ324 LED
XRZ334 LED
RRZ324 LED
RRZ334 LED
GRY224 LED
GRY234 LED
Advertisement
Related Manuals for WE-EF XRY324 LED
Summary of Contents for WE-EF XRY324 LED
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Bollard XRY324 LED XRY334 LED RRY324 LED RRY334 LED XRZ324 LED XRZ334 LED RRZ324 LED RRZ334 LED GRY224 LED GRY234 LED Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards.
- Page 2 Bollard XRY324** RRY324** GRY224** XRY334** RRY334** GRY234** XRZ324* RRZ324* XRZ334* RRZ334* IP55*, IP66**, IK10, Class I, ta = 40°C...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out by a suitably quali ed and trained professional. -
Page 4: Installation
Installation The product must be installed and maintained by a suitably quali ed professional in compliance with latest building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: If the luminaire is modi ed by anybody other than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. -
Page 5: Installation Procedure
Installation Procedure It is recommended to incorporate the optional planted root to ensure maximum stability. 1) Switch off mains electrical supply. 2) Check that rating shown on luminaire label conforms with mains electrical supply. 05/17 IP55 220-240V/50Hz, 1-10v XRZ334 114-9632 SOE XXXXXXX LED 4000K 12W item no. - Page 6 5) Connect luminaire cable E to mains supply 6) Place watertight terminal connector G and cable F in watertight terminal connector G excess cable inside post H. (not supplied by WE-EF). CIRCUIT ON/OFF 1-10 V DALI PHASE PHASE PHASE NEUTRAL...
- Page 7 Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9233W0219 © WE-EF 2019 Technical speci cations are subject to change.
- Page 8 WE-EF LEUCHTEN Installation and Maintenance Instructions Planted Root ESV4 ESV2 ESV6...
- Page 9 Planted Root ESV4 300-0461 ESV4 300-0464 Suitability Suitability 1. KTX234 1. CFY259 2. KTY234 2. GRY234 3. ZFY230 3. RRY324 4. GRY224 4. RRZ324 5. Short post 5. XRY324 6. XRZ324 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334 1. QSI254 2.
- Page 10 Planted Root ESV2 300-9115 ESV6 300-0457 Suitability Suitability 1. PSY414/424 1. LTM440 2. LTM444 3. AMW-C 4. AMF-C 5. AMF-S 6. AML-C ESV6 300-0824 Suitability 1. AML-C 2. FLA461...
-
Page 11: Installation Instruction
Installation Instruction 1) Note: It is the responsibility to installer to 2) Please note, ESV4 and ESV6 must be ensure the suitability of the ESV planted root orientated correctly for different products. for any local or national structural requirements In both instances conduit entry can be rotated for installation, and that planted root is suitable to match cable routing. - Page 12 5) For all other product that use ESV6 please orientate planted root as shown (base plate connections/conduit. is parallel to the pathway). For this installation, use 40 mm long M16 bolts supplie. 7) Place the ESV in the form work for concrete 8) Fit the nominated bolts through mounting pad, ensuring orientation, position and levels are correct.
- Page 13 9) Pour concrete to desired level depending on requirement of soil, paver or concrete. Ensure (as per luminaire instructions) onto mounting Concrete Paver Soil...
