Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.
Surge Protection
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and
secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LIGHTING
Installation and Maintenance
Instructions
Bollard
CFY259 LED
ZFY230-AP LED
KTY234-AP LED
INSTALLER
HOTLINE
+61 458 933 399
7am – 7pm AEST
Advertisement
Related Manuals for WE-EF CFY259 LED
Summary of Contents for WE-EF CFY259 LED
- Page 1 WE-EF LIGHTING Installation and Maintenance Instructions Bollard CFY259 LED ZFY230-AP LED KTY234-AP LED INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST Do not open during installation Surge Protection This product is factory-sealed. For comprehensive protection of a luminaire installation against lightning and...
- Page 2 Bollard ZFY230-AP ZFY230-AP H = 600 mm H = 1000 mm ø 180 ø 180 1000 IP66, Class I, ta = 25°C Weight for ZFY230-AP for ZFY230-AP 1000 Accessories: Planted root – Galvanised steel. ESV4 for ZFY230-AP 300-0461 ESV4...
- Page 3 Bollard KTY234-AP KTY234-AP H = 600 mm H = 1000 mm IP66, Class I, ta = 25°C Weight for KTY234-AP for KTY234-AP 1000 Accessories: Planted root – Galvanised steel. ESV4 for KTY234-AP 300-0461 ESV4...
- Page 4 Bollard CFY259 CFY259 H = 600 mm H = 1000 mm ø 240 ø 240 1085 CFY259 CFY259 H600 / 6 LED H1000 / 2x6 LED 65° ø 190 ø 240 IP66, Class I, ta = 25°C Weight WARNING : HEAVY ITEMS for CFY259 Ensure correct handling for CFY259...
-
Page 5: Maintenance
In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open the luminaire or remove the bollard head while mains supply is switched on. The luminaire head unit B is factory sealed, warranty will be void if opened without authorisation from WE-EF Lighting or nominated agent. -
Page 6: Installation Procedure
Installation Installation Procedure The product must be installed and maintained by a The luminaire is suitable for installation directly on to an even surface, however it is recommended to building/construction and/or electrical regulations and incorporate the optional planted root to ensure relevant legislation. - Page 7 Fig. 2 Torque: Screw Torque max. 2.0 Nm max. 4.0 Nm max. 6.0 Nm max. 15.0 Nm max. 100.0 Nm Fig. 1...
- Page 8 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING INSTALLER United Kingdom HOTLINE Tel +44 844 880 5346 +61 458 933 399 Fax +44 844 880 5347 7am – 7pm AEST info.uk@we-ef.com TO9235W0218 © WE-EF 2018 subject to change.
