Surge Protection
This product features built-in surge protection circuitry in compliance
with applicable standards.
For comprehensive protection of a luminaire installation against lightning
and electrical surges, it is essential to cover mains supply and data input
lines at the distribution board level, by using respective primary (Type 1)
and secondary (Type 2) surge arrestors in compliance with EN61643-11/
IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and
activated prior to luminaire installation. Also, disconnect luminaires
before operating high-power devices such as, for example, electrical
arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollard
XRY324 LED
XRY334 LED
RRY324 LED
RRY334 LED
XRZ324 LED
XRZ334 LED
RRZ324 LED
RRZ334 LED
GRY224 LED
GRY234 LED
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for WE-EF XRY324 LED
Summary of Contents for WE-EF XRY324 LED
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Bollard XRY324 LED XRY334 LED RRY324 LED RRY334 LED XRZ324 LED XRZ334 LED RRZ324 LED RRZ334 LED GRY224 LED GRY234 LED Surge Protection This product features built-in surge protection circuitry in compliance with applicable standards.
- Page 2 Bollard XRY324** RRY324** GRY224** XRY334** RRY334** GRY234** XRZ324* RRZ324* XRZ334* RRZ334* IP55*, IP66**, IK10, Class I, ta = 40°C...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried Warning: Do not open luminaire while mains supply is switched on. Product Dimensions: GRY224 ø... -
Page 4: Installation
– DO NOT INSTALL ON WET CONCRETE! Handling: handled with care, scratches and damage to the coated surface can result in galvanic corrosion. A WE-EF warranty does not cover any adverse reaction or damage, due to improper installation and requests that our recommendations are followed. -
Page 5: Installation Procedure
Installation Procedure It is recommended to incorporate the optional planted root to ensure maximum stability. 2) Check that rating shown on luminaire label conforms with mains electrical supply. 05/17 IP55 XRZ334 220-240V/50Hz, 1-10v 114-9632 SOE XXXXXXX LED 4000K 12W item no. XXX (example) 3) A suitable recess to be provided for planted 4) Remove cover B from cast base C by loosening... - Page 6 5) Connect luminaire cable E to mains supply 6) Place watertight terminal connector G and cable F in watertight terminal connector G excess cable inside post H. (not supplied by WE-EF). CIRCUIT ON/OFF 1-10 V DALI PHASE PHASE PHASE NEUTRAL...
- Page 7 WE-EF SWITZERLAND WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9233W0823 © WE-EF 2023 subject to change.
- Page 8 WE-EF LEUCHTEN Installation and Maintenance Instructions Planted Root ESV4 ESV6 ESZ4...
- Page 9 Planted Root ESV4 300-0461 ESV4 300-0464 Suitability Suitability 1. KTX234 1. CFY259 2. KTY234 2. GRY234 3. ZFY230 3. RRY324 4. GRY224 4. RRZ324 5. Short post 5. XRY324 6. XRZ324 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334 1. QSI254 2.
- Page 10 Planted Root ESV6 300-0824 ESV6 300-0457 Suitability Suitability 1. AML-C 1. LTM440 2. FLA461 2. LTM444 3. AMW-C 4. AMF-C 5. AMF-S 6. AML-C ESZ4 300-9115 ESZ4 300-9090 Suitability Suitability 1. PSY414/424 1. MRY224...
-
Page 11: Installation Instruction
Installation Instruction 1) Note: It is the responsibility to installer to 2) Please note, ESV4 and ESV6 must be ensure the suitability of the ESV/ESZ planted root for any local or national structural require- In both instances conduit entry can be rotated ments for installation, and that planted root is to match cable routing. - Page 12 5) For ESZ4 please orientate planted root as shown (base plate is parallel to the pathway). cal connections/conduit. For this installation, use 30 mm long M12 bolts for PSY planted root and 35 mm long M10 bolts for MRY planted root. M12 x 30 M10 x 35 7) Place the ESV/ESZ in the form work for con-...
- Page 13 9) Pour concrete to desired level depending on requirement of concrete, paver or soil. Ensure (as per luminaire instructions) onto mounting level. Concrete Paver Soil...
- Page 14 WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9257W0124 © WE-EF 2024 Technical specifications are subject to change.
