WE-EF ZFY230 LED Installation And Maintenance Instructions Manual

Bollard
Hide thumbs Also See for ZFY230 LED:

Advertisement

Quick Links

Download this manual
Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the
use of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollard
ZFY230 LED

Advertisement

loading
Need help?

Need help?

Do you have a question about the ZFY230 LED and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for WE-EF ZFY230 LED

Summary of Contents for WE-EF ZFY230 LED

  • Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Bollard ZFY230 LED Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards. document for details.
  • Page 2 Bollard ZFY230 ZFY230 H = 600 mm H = 1000 mm ø 180 ø 180 1000 IP66, Class I, ta = 25°C Accessories: Planted root – Galvanised steel. ESV4 for ZFY230 300-0461 ESV4...

  • Page 3: Maintenance

    Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. To remove the head of the luminaire during maintenance, loosen screw J with Torx T-20 tool and rotate it anti-clockwise until it can be lifted up.

  • Page 4: Installation Procedure

    I. 6) Connect luminaire cable E to mains supply cable F in watertight terminal connector G (not supplied by WE-EF): a) ON/OFF (L = Phase, N = Neutral, = Earthing) b) 1-10V/DALI (L = Phase, N = Neutral, = Earthing, DA/DA = DALI control line, D-/D+ = 1-10V control line).
  • Page 5 Torque: Screw Torque max. 2.0 Nm max. 4.0 Nm max. 6.0 Nm max. 15.0 Nm max. 100.0 Nm...
  • Page 7 Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9235W0219 © WE-EF 2019 Technical speci cations are subject to change.
  • Page 8 WE-EF LEUCHTEN Installation and Maintenance Instructions Planted Root ESV4 ESV2 ESV6...
  • Page 9 Planted Root ESV4 300-0461 ESV4 300-0464 Suitability Suitability 1. KTX234 1. CFY259 2. KTY234 2. GRY234 3. ZFY230 3. RRY324 4. GRY224 4. RRZ324 5. Short post 5. XRY324 6. XRZ324 ESV4 300-0586 ESV4 300-0459 Suitability Suitability 1. XRY334 1. QSI254 2.
  • Page 10 Planted Root ESV2 300-9115 ESV6 300-0457 Suitability Suitability 1. PSY414/424 1. LTM440 2. LTM444 3. AMW-C 4. AMF-C 5. AMF-S 6. AML-C ESV6 300-0824 Suitability 1. AML-C 2. FLA461...

  • Page 11: Installation Instruction

    Installation Instruction 1) Note: It is the responsibility to installer to 2) Please note, ESV4 and ESV6 must be ensure the suitability of the ESV planted root orientated correctly for different products. for any local or national structural requirements In both instances conduit entry can be rotated for installation, and that planted root is suitable to match cable routing.
  • Page 12 5) For all other product that use ESV6 please orientate planted root as shown (base plate connections/conduit. is parallel to the pathway). For this installation, use 40 mm long M16 bolts supplie. 7) Place the ESV in the form work for concrete 8) Fit the nominated bolts through mounting pad, ensuring orientation, position and levels are correct.
  • Page 13 9) Pour concrete to desired level depending on requirement of soil, paver or concrete. Ensure (as per luminaire instructions) onto mounting Concrete Paver Soil...
  • Page 14 WE-EF HELVETICA WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9257W0420 © WE-EF 2020 subject to change.
