Virtual Com Port; Atmel Data Gateway Interface - Atmel ATMEGA256RFR2 Xplained Pro User Manual

Table 4-14. JTAG connections.
Pin on ATmega256RFR2
PF4
PF5
PF6
PF7
RSTN
4.3.2

Virtual COM port

The Embedded Debugger act as a Virtual Com Port gateway by using one of the ATmega256RFR2 UARTs.
For further information on how to use the Virtual COM port see
Table 4-15. Virtual COM port connections.
Pin on ATmega256RFR2
PD2
PD3
4.3.3

Atmel Data Gateway Interface

The Embedded Debugger features an Atmel Data Gateway Interface (DGI) by using either a SPI or TWI
port. The DGI can be used to send a variety of data from the ATmega256RFR2 to the host PC. For further
information on how to use the DGI interface see
Table 4-16. DGI interface connections when using SPI.
Pin on ATmega256RFR2
PB0
PB1
PB2
PB3
Table 4-17. DGI interface connections when using TWI.
Pin on ATmega256RFR2
PD0
PD1
Four GPIO lines are connected to the Embedded Debugger. The EDBG can monitor these lines and time
stamp pin value changes. This makes it possible to accurately time stamp events in the ATmega256RFR2
application code. For further information on how to configure and use the GPIO monitoring features see
"Embedded Debugger" on page
Table 4-18. GPIO lines connected to the EDBG.
Pin on ATmega256RFR2
PE2
PE3
PE5
PE6
Function
JTAG TCK
JTAG TMS
JTAG TDO
JTAG TDI
RESET
Function
UART RXD (ATmega256RFR2 RX line)
UART TXD (ATmega256RFR2 TX line)
"Embedded Debugger" on page
Function
Slave select (ATmega256RFR2 is Master)
SPI SCK (Clock Out)
SPI MOSI (Master Out, Slave in)
SPI MISO (Master In, Slave Out)
Function
SCL (Clock line)
SDA (Data line)
6.
Function
GPIO0
GPIO1
GPIO2
GPIO3
