Setup - Operation
™
HFR
Hydraulic, Plural-Component, Fixed-Ratio Proportioner.
For pouring and dispensing sealants and adhesives and polyurethane foam.
For professional use only. Not for use in explosive atmospheres.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
See page 4 for model information and maximum
working pressure.
Patent Pending
313997A
ENG
24C352_313998_7e
