Wyrestorm EX-70-4K-ARC Quickstart Guide Quick Start Manual page 4

Specifications
Audio and Video
Audio Formats
Video Resolution
Color Depth
Maximum Pixel Clock
Communication and Control
HDBaseT
HDMI
IR
RS-232
ARC (Audio Return
Channel)
Power
PoH
Power Supply
Max Power Consumption
Environmental
Operating Temperature
Storage Temperature
Dimensions and Weight
Height
Width
Depth
Weight
Regulatory
Safety and Emission
RoHS
Warranty Information
This product is covered by a 3 year limited parts and labor warranty. During this period there will be no charge for unit
repair, component replacement or complete product replacement in the event of malfunction. The decision to repair or
replace will be made by the manufacturer. This limited warranty only covers defects in materials or workmanship and
excludes normal wear and tear or cosmetic damage.
Visit the product page located at
technical information not provided in this document and warranty terms & conditions.
Copyright © 2015 WyreStorm Technologies |
EX-70-4K-ARC Quickstart Guide | 160225
2ch analog and Up to 7.1 DTS-HD
Master Audio and Dolby TrueHD
1920x1080@60Hz (1080p60)
4096x2160p@30Hz 4:2:0
36bit
297 MHz
HDCP 1.4 | EDID | ARC | PoH | Bi-
directional IR and RS-232
HDCP 1.4 | EDID | ARC
DVI/D supported with adapter (not
included)
Bi-directional over HDBaseT
Bi-directional over HDBaseT
Returns audio to source location from
remote display via HDBaseT
48V 15.4W
Input: 100~240V AC 50/60Hz
Output: 12V DC 2A
26.5W
32°F ~ 113°F (0°C ~ 45°C)
10% ~ 90%, non-condensing
-4°F ~ 140°F (-20°C ~ 70°C)
10% ~ 90%, non-condensing
24.9mm/0.98in
220mm/8.66in
89.9mm/3.54in
0.58kg/1.28lbs
CE | FCC
Compliant
wyrestorm.com for additional information on this product including important
wyrestorm.com
Troubleshooting
No or Poor Quality Picture (snow or noisy image)
• Verify that power is connected to the transmitter and receiving device. If
using a display with a built in receiver, verify that the device is powered
on.
Note: When using PoH, to power the transmitter, verify that the
HDBaseT cable is properly terminated per the
section.
• Verify that the transmitter supports the output resolution of the source.
See Supported Video Resolutions.
• Verify that the receiving device and display support the output
resolution of the source. Configure EDID Settings to a lower resolution.
If transmitting 3D or 4K, verify that the HDMI cables used are 3D or 4K
rated.
• Verify that the HDBaseT cable is properly terminated per the
Wiring section.
• Verify that all source and HDBaseT connections are not loose and are
functioning properly.
No or Intermittent 3rd party Device Control
• Verify that the IR cable(s) is properly terminated.
See IR Wiring
• Verify that the IR emitter is located near the IR receiver on the device.
Troubleshooting Tips:
• WyreStorm recommends using a cable tester or connecting the cable
to other devices to verify functionality.
• Use a flashlight to locate the IR receiver behind any tinted panels on the
device being control.
North America: 518-289-1294 | EMEA/ROW: 44 (0) 1793 230 343
4 of 4
HDBaseT Wiring
