Page 1: Operating Instructions
Model No EX0101-WH1/WH2 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual carefully before using our product. - Page 2 Introduction EX0101-WH1/WH2 is a HDMI extender while using CAT-5E/6 cable as transmission media. Benefits from using EX0101-WH1/ WH2: The length of HDMI cable is fixed and unchangeable after it is produced. Because the HDMI connector can only be soldered or terminated by professional worker in factory, the users can not reduce or increase by themselves.
-
Page 3: Table Of Contents
Contents HDMI Extender ....................1 Product Overview ..................1 Features ....................... 1 Package Contents ..................3 Connections and Operations ................ 3 Specifications ....................4 Panel Descriptions ..................5 Typical Application ..................6 Maintenance ....................7 Product Service .................... 7 ● Provided Service ................... 7 ●... -
Page 5: Hdmi Extender
HDMI Extender (By single CAT-5E/6E cable) Product Overview ( Model Number: EX0101-WH1/ WH2 ) ■ Features ■ One pair as a full functional module, no need for setting. Use single UTP LAN cable (CAT-5E/6) to substitute HDMI cable to achieve long distance transmission. - Page 6 Notice We reserve the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. Warning To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth.
-
Page 7: Package Contents
3) Connect the HDMI sink( such as HD-LCD、HD-DLP）to EX0101-WH2. 4) Connect the IR TX UNIT into EX0101-WH1 IR TX; Connect the IR RX UNIT into EX0101-WH2 IR RX. 5) Connect the IR RX UNIT into EX0101-WH1 IR RX; Connect the IR TX UNIT into EX0101-WH2 IR TX. -
Page 8: Specifications
(repeat the source to the sink) Support DTS-HD, Dolby-HD (repeat the Output Audio source to the sink) Maximum Transmission Distance 100 meters Power Supply 5VDC 2.5Watts (EX0101-WH1) Power Consumption 5Watts (EX0101-WH2) 117mmH×114mmW×33mmD/4.61’’W× Dimensions 4.49’’H×1.30’’D Mass (Main unit) 0.76Kg / 1.68lb (Pairs) NOTE1: Specifications are subject to change without notice. -
Page 9: Panel Descriptions
Panel Descriptions ■ 1. EX0101-WH1 Front Panel 1、 HDMI Input 2、 Status of Power. When power input on, the LED inside lights 3、 Status of Link. When UTP cable connected, the LED inside lights 4、 Power input 5VDC 5、 IR RX 6、... - Page 10 2. EX0101-WH2 Front Panel 1、 HDMI Output 2、 Status of Power. When power input on, the LED inside lights 3、 Status of Link. When UTP cable connected, the LED inside lights 4、 Power input 5VDC 5、 IR RX 6、 IR TX Back Panel 1、...
-
Page 11: Typical Application
Typical Application ■ Power cable connection (optional) ■ If use power cable to connect this two units as above, only one unit needs power adapter. The other unit can fetch power through the power cable. Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. -
Page 12: Mail-In Service
The DC power supply cord or AC adaptor has been damaged; Objects or liquids have gotten into the unit; The unit has been exposed to rain; The unit does not operate normally or exhibits a marked change in performance; The unit has been dropped or the cabinet damaged. Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. -
Page 13: Warranty Limits And Exclusions
period indicated as below, （Parts (1) Year， Labor(90) Days）which starts with the date of original purchase (“Limited Warranty period”), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be made by the warrantor. - Page 14 or damage to media or images, data or other recorded content. The items listed are not exclusive, but are for illustration only.) Parts and service, which are not covered by this limited warranty, are your responsibility.
