4K UHD HDBaseT Extender Set
with HDCP 2.2 & 2-way PoH
EX-70-G2
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
Identifying Product Versions
This product was released in 2 different versions which contain different
chassis designs and feature sets. The differences are identified throughout
this document in order to make installation and use easier. Versions can
be identified by a v# after the model number on the product chassis model
number sticker. Note that version 1 of this product may not contain a v1 after
the product while all version 2s will contain a v2 after the model number.
Basic Wiring Diagram
IR to Control System
CAB-IR-LINK (Sold Separately)
18V DC 1A
Power Supply
Copyright © 2018 WyreStorm Technologies |
EX-70-G2 Quickstart Guide | 180919
HDMI Source
IR Emitter
HDMI
EX-70-G2 Transmitter (TX)
wyrestorm.com
In the Box
1x EX-70-G2 Transmitter
1x EX-70-G2 Receiver
1x 18V DC 1A Power Supply (US/UK/EU)
1x IR Emitters
1x IR Receivers
2x 3‐pin Screw Down Male Phoenix Connectors
4x Mounting Brackets (2x for TX | 2x for RX)
1x Quickstart Guide (this document)
HDMI Display
IR Receiver
EX-70-G2 Receiver (RX)
HDBaseT
Cat6/6a/7
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
1 of 4
Quickstart Guide
IR Emitter
HDMI
KEY
HDMI
HDBaseT Cat5e/6/6a
IR TX and RX
Power
support@wyrestorm.com
Advertisement
Table of Contents
Related Manuals for Wyrestorm EX-70-G2 Series
Summary of Contents for Wyrestorm EX-70-G2 Series
- Page 1 4K UHD HDBaseT Extender Set with HDCP 2.2 & 2-way PoH Quickstart Guide EX-70-G2 WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. Identifying Product Versions In the Box...
- Page 2 HDMI In (TX) Supports HDMI and DVI/D (requires adapter - HDMI Out (RX) not included). Copyright © 2018 WyreStorm Technologies | wyrestorm.com UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) 2 of 4 EX-70-G2 Quickstart Guide | 180919...
- Page 3 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 4 Safety and Emission CE | FCC | RoHS Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies LLC warrants that its products to be free from defects in material and workmanship under normal use for a period of five (5) years from the date of purchase.
