Simplex 4010ES Quick Reference Manual page 2

SIMPLEX 4010ES with ESS Main Board
Descrip�on
Terminal Block
Provides 2 fault isolated loops of IDNet +.
TB1 IDNet Connec�ons
TB1 (1-4) Loop A, TB1 (5-8) Loop B
Each IDNAC circuit has a 4 posi�on terminal block.
TB2 IDNAC Connec�ons
TB2 (1-4) IDNAC 1,TB2 (5-8) IDNAC 2
Provides 2 posi�ons for wiring the aux power
TB3 Aux/Simple NAC
and reverse polarity supervision circuit.
A 32V, 2A relay is provided with both
TB4 Relay
NO and NC contacts.
LED Name
LED 1 IDNet Nega�ve Earth Fault
LED 2 IDNet Posi�ve Earth Fault
LED 3 IDNet Trouble
LED 4 IDNet Com
LED 5 IDNet Loop A Trouble
LED 6
IDNet Loop B Trouble
LED 7 IDNAC 1 Trouble
LED 8 IDNAC 2 Trouble
LED 9
AC
LED 10 Comm Loss
LED 11 E ESS debug LED
LED 12 D ESS debug LED
LED 13 C ESS debug LED
LED 14 B ESS debug LED
LED 15 A ESS debug LED
LED15 LED14 LED13 LED12 LED11
A B C D E
OFF OFF OFF OFF OFF No Trouble: There are no troubles detected on the ESS.
ON OFF OFF OFF OFF AC Fail: The AC power is disconnected, but the ba�ery is working.
OFF ON OFF OFF OFF Low Ba�ery: The ba�ery is under 22V.
Ba�ery Cutout: The Ba�ery charge is below 20V. At this point, if Jumper P19
ON ON OFF OFF OFF
is set to "ba�ery disconnect when depleted" the system shuts down.
Depleted/Missing Ba�ery: If jumper P19 is not set to "ba�ery disconnect
OFF OFF ON OFF OFF
when depleted", this trouble appears when the ba�ery charge is below
20V. This code also appears if the system cannot detect the ba�ery.
ON OFF ON OFF OFF Charger Trouble: There is a trouble with the ba�ery charger.
OFF ON ON OFF OFF Card Overcurrent: The module is drawing too much current.
ON ON ON OFF OFF Nega�ve Earth: The circuit is shorted to ground on the nega�ve wire.
OFF OFF OFF ON OFF Posi�ve Earth: The circuit is shorted to ground on the posi�ve wire.
City Circuit 1 Trouble: The trouble configured on the City Card's
ON OFF OFF ON OFF
Circuit 1 has been triggered.
City Circuit 2 Trouble: The trouble configured on the City Card's
OFF ON OFF ON OFF
Circuit 2 has been triggered.
AuxNAC Open: Depending on the chosen configura�on,
ON ON OFF ON OFF
either the Aux circuit or the NAC Circuit is open.
AuxNAC Short: Depending on the chosen configura�on,
OFF OFF ON ON OFF
either the Aux circuit or the NAC Circuit is experiencing a short circuit.
AuxNAC Overcurrent: Depending on the chosen configura�on,
ON OFF ON ON OFF
either the Aux circuit or the NAC circuit is drawing too much current.
P2 P3
Debug LED
Descrip�on
TB1 TB2
P4
P13
P9
P7
P Connectors
and Switch
P2 IDNet 4100 Comms Enable
P3 and P4 Jumpers select IDNet Class A/B
City/Relay Card, A 10-posi�on connector is provided for the ribbon harness that goes to a City Card or Relay Card
P7
P9 Posi�ve ba�ery connec�on
P11 Connec�on plug for an op�onal Dual Class A Isolator (DCAI) card
P13 Nega�ve ba�ery connec�on
Disables 4100 Communica�ons between the power supply and IDNAC func�ons
P18
P19 Ba�ery Disconnect (Canadian Opera�on Jumper)
SW1 Scroll Switch if mul�ple troubles
P11
P19
P18
Descrip�on
SW1
