SET-UP AND INSTALLATION
CAUTION
Do not power the counterweight into the counterweight-
to-hoist mounting pins.
17. Slowly extend the counterweight removal cylinders (5)
(Figure 4-11) so the counterweight-to-hoist mounting
pins (12) (Figure 4-11) take the weight of the
counterweight (1) (Figure 4-11).
18. Connect the auxiliary hoist hydraulic lines and electrical
wires as tagged and disconnected earlier.
19. Remove the counterweight support from the front of the
carrier. Refer to Counterweight Stand Removal, page 4-
16.
4-16

Counterweight Stand Removal

1. Attach an adequate lifting device with slings to the
counterweight stand (1) (Figure 4-10).
2. Loosen jam nut (7) (Figure 4-10).
3. Rotate foot plates (5) (Figure 4-10) on the counterweight
stand (1) (Figure 4-10) away from the outrigger box (2)
(Figure 4-10).
4. Remove the counterweight stand (1) (Figure 4-10) to
carrier frame hitch pins (4) (Figure 4-10).
5. Using the lifting device with slings, remove the
counterweight stand (1) (Figure 4-10).
6. Repeat for the other counterweight stand.
