SET-UP AND INSTALLATION
Item
1 11 m (36 ft) Boom Extension Base Section
2 7 m (23 ft) Boom Extension Fly Section
3 Fly Rear Stowage Bracket
4 Base Extension Sheave
5 Guide Rail
6 Fly Sheave
7 Mast Assembly
8 Offset Lugs
9 Offset Pivot Pin
10 Boom Extend Anchor Fittings
11 Boom Nose Anchor Lugs
12 Front Stowage Bracket/Pivot Shaft
13 Middle Stowage Bracket
4-22
Description
Published 3-1-2018, Control # 559-03
RT9130E-2 OPERATOR MANUAL
Item
14 Fly Sheave Connection
15 Lever
16 Spring Pin
17 Pressure Spring
18 Retaining Pin
19 Clip Pin
20 Support
21 Lifting Plate
22 Threaded Plate
23 Adjusting Bolt
24 Spring Latch
25 Holder Bracket
Description
