FOOT L E VEL
0.0
-1.0
-2.0
-3.0
-4.0
-5.0
-6.0
-7.0
-8.0
-9.0
0.00
EXAMPLE
A 15 m line is set up at 1.25m above foot level, and a 2m Spanset Lanyard is used to connect the
user. the necessery clearance required is 5.2m below the users feet.
If you require more detailed installation information, please contact Spanset.
FOOT L E VEL
0.0
-1.0
-2.0
-3.0
-4.0
-5.0
-6.0
-7.0
0.00
IMPORTANT: Please note that the test results were achieved using SpanSet fall arrest lanyards, and a
100kg (16st) mass, therefore clearances for persons over 100kg should be increased.
Only SpanSet products Ref: HSL, TP or XP are compatible with these clearance figures. These figures
cannot be used with products from any other manufacturer.
Two persons - For installation guidance see page 3.
2m Lanyar d
1.25
HSL Position Above User Foot Level (m )
1.5m Lanyard
1.25
HSL Position Above User Foot Level (m )
HAZARD CLEARANCE GUIDE
2.00
2.00
GBR
GBR
5m Line
10m Line
15m Line
20m Line
(Other EN355 + HSL)
Fig. K
5m Line
10m Line
15m Line
20m Line
Fig. L
7
