Table 3-1. Alarm Characteristics
LIMITATION
Height Limitation
Boom Up/Down
Radius
Swing
Virtual wall
Note that the audible alarm can be canceled. By pressing the
Tab button on the display. Refer to item 1 in (Figure 3-51). It
can only be canceled once the boom is no longer being
moved. When boom motion again becomes apparent in the
control system, the audible alarm will be restored.
Grove
POSITION
3 m (10 ft) before limit
1.5 m (5 ft) before limit
At limit
10 deg before limit
5 deg before limit
At limit
3 m (10 ft) before limit
1.5 m (5 ft) before limit
At limit
10 deg before limit
5 deg before limit
At limit
3 m (10 ft) before limit
1.5 m (5 ft) before limit
At limit
Published 02-21-2019, Control # 611-05
OPERATING CONTROLS AND INDICATORS
ALARM
Slow beeping
Fast beeping
Solid sound
Slow beeping
Fast beeping
Solid sound
Slow beeping
Fast beeping
Solid sound
Slow beeping
Fast beeping
Solid sound
Slow beeping
Fast beeping
Solid sound
9072
3
1
2
FIGURE 3-51
