P P G D I G I M A T C H S P E C T R O P H O T O M E T E R
Important
You should charge the battery regularly if you are not using the device for an extended amount of time. Store
it in a cool environment when not in use to maintain battery performance. The battery charge temperature
range is 5°C to 40°C (40°F to 105°F).
The lifespan of lithium-ion batteries typically decays to 80% capacity after approximately 700 charge cycles.
The number of measurements you can expect to achieve from one full charge is reduced. Please contact
Technical Support to replace the battery pack.
NOTE: A charge cycle is defined as several partial charges equaling 100%. Partial charge and discharge
cycles will help maintain the life of the battery.
Please avoid full discharge and charge cycles. Do not discharge the battery below 20% (battery icon red.)
Do not measure with device charging. Only measure with device disconnected from cable.

Setup

Powering on the Device

Press and hold the Measure and Power On/Off button (1)
for 3 seconds to turn on the device.
If the device does not power up after pressing the button,
the battery may require charging. Refer to Section

Connecting the USB-C Cable.

Powering off the Device
Press and hold the On/Off button for one second. You can
also power off the device by tapping the power icon located
in the Settings screen.
When powered-up, the device goes through a diagnostics test. The status LED and screen illuminate white,
followed by a splash screen before the main screen. This startup sequence will take a few seconds to
complete.
Splash Screen
Connecting the USB-C Cable
1. Install the software application if not already installed. Refer to the software documentation for additional
information.
2. Unpack the docking station. Insert the white tile and the camera test target into the docking station.
10
This icon at the top of the screen would indicate the battery has a sufficient charge for a
substantial number of measurements.
This icon at the top of the screen would indicate the battery pack is low, but measurements
are still possible. Battery should be charged soon.
The "lightning bolt" in the center of the battery icon at the top of the screen indicates the
battery is charging.
Main Screen
(1)
(1)
