  • Page 1 User Guide...

  • Page 2: Table Of Contents

    To view E label Compliance information for WiFi devices, choose Settings > Device Information > Device Label CE Declaration Hereby, X-Rite, Incorporated, declares that this model is in compliance with the essential requirements and other relevant provisions of Directive(s) EMC Directive 2014/30/EU, LVD 2014/35/EU and RoHS 2011/65/EU.
  • Page 3 être installées ou utilisées conjointement avec d'autres antennes ou émetteurs. REMARQUE : Les changements ou modifications apportés à cet équipement sans l'autorisation expresse de X-Rite, Incorporated peuvent annuler l'autorisation d'utilisation de cet équipement accordée par la FCC.
  • Page 4 Zentri Module No. AMW106 Equipment Information Use of this equipment in a manner other than that specified by X-Rite, Incorporated may compromise design integrity and become unsafe. To avoid discomfort, do not look directly into the measurement optics when the instrument is on.

  • Page 5: Packaging

    RapidMatch GO Spectrophotometer Atmel's name may not be used to endorse or promote products derived from this software without specific prior written permission. DISCLAIMER: THIS SOFTWARE IS PROVIDED BY ATMEL "AS IS" AND ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT ARE DISCLAIMED.

  • Page 6: Powering On

    RapidMatch GO Spectrophotometer Powering On The power/measure button is used to initiate the instrument from a power off state. Simply press the button for about one second to turn on the instrument. If the instrument does not power up after pressing the power button, the battery may require charging.

  • Page 7: Measure Button

    RapidMatch GO Spectrophotometer During charging, the instrument switches on and indicates charging with a “lightning bolt” in the battery icon. The instrument will not power completely off while plugged into the computer USB port, however, it will go into standby mode.

  • Page 8: Contact Sensors, Indicators And Leds

    RapidMatch GO Spectrophotometer Contact Sensors, Indicators and LEDs The indicators in the screen are arranged in the same pattern as the contact sensors located around the measurement port. • Green Indicator: ideal contact is being applied to the corresponding sensor. A measurement can be taken when all three indicators illuminate green.

  • Page 9: Navigating The Screen

    RapidMatch GO Spectrophotometer Header bar Job List mode Connect WiFi Settings mode Job List Mode: This mode is the main mode of operation. Jobs are added, selected, deleted, and measurements are taken in this mode. Settings Mode: The settings mode is used to set and edit the instruments configuration options, and to enter the calibration mode.

  • Page 10: Wifi Mode

    RapidMatch GO Spectrophotometer Opening Settings and Jobs Settings and jobs are accessed by tapping the corresponding icon on the Home screen. For this example, the Settings icon was tapped to open the Settings screen. See Settings Mode descriptions that follow. WiFi Mode The WiFi Mode is used to connect to the available networks when activated in the Settings mode.
  • Page 11 RapidMatch GO Spectrophotometer To access, tap Calibration. Refer to the Calibration mode section later in this manual for detailed information on performing a calibration. Self Test This option is used to run a self test of the instrument. To activate, tap Self Test and then place the instrument on the white calibration tile.
  • Page 12 RapidMatch GO Spectrophotometer Language This option is used to set the language that is displayed on the instrument during operation. To set the language, tap Language and then tap the desired language. N (measurement number) Option This option is used to set the default number of measurements when using “Add new Job”...

  • Page 13: Calibration

    RapidMatch GO Spectrophotometer Factory Reset Option This option is used reset the instrument to its factory default settings. All stored sample will also be deleted when activated. Select Yes to reset to the factory default settings or select No exit the setting without resetting. 11.

  • Page 14: Measurement

    RapidMatch GO Spectrophotometer Position the instrument over the white tile by locating the two pins in the Calibration reference into the holes in the measurement base. NOTE: The pins are keyed and will only insert in one direction. When ready, tap Calibration and then tap Yes to start calibration. Do not touch the instrument throughout the measurement sequence.
  • Page 15 RapidMatch GO Spectrophotometer green checkmark. Downloaded jobs that have a green checkmark have already been completed. Completed job Available job Locate the measurement port in the bottom of the instrument over the first measurement area while viewing the screen (1). Gently rock the instrument until all three positioning indicators (2) in the screen turn green.
  • Page 16 RapidMatch GO Spectrophotometer If the job was created on the instrument using the Add New Job feature, you can edit the name if desired. Click on the Edit icon at the button of the screen and enter a job name using the virtual keyboard. Click the Checkmark icon to save the job name.

  • Page 17: Cleaning

    RapidMatch GO Spectrophotometer Tap the delete all jobs icon at the bottom of the screen. A message appears asking you to confirm that you want to delete the job. Tap Yes to confirm or No to return to the Job List screen. 13.

  • Page 18: Troubleshooting

    RapidMatch GO Spectrophotometer Capacity: 2.15 Ah Max. discharge current: 4A Max. charge current: 2.15A Inner resistance: <= 120 mΩ Compliance: UN38.3, IEC62133B, CE Protection: over current, over charge, over discharge 15. Troubleshooting Prior to contacting PPG support department for instrument problems, try the applicable solution(s) described below.
  • Page 19 RapidMatch GO Spectrophotometer frozen. and hold the power/measure button for 10 seconds and then release. Instrument turns off. Instrument can be started normally. Measurement Material being Repeat measurement. error or results measured is damaged appear (e.g. scratched). inaccurate. Calibration was Clean the calibration reference performed on a dirty and repeat the calibration per...

  • Page 20: Service Information

    RapidMatch GO Spectrophotometer calibrate. sample surface. sure that all 3 sensor indicators on the screen turn green. Contact sensor(s) are Open a new job to show the 3 not working correctly. sensor indicators on the screen Sensors may be stuck and place the instrument on a flat due to dirt or paint;...
  • Page 21 X-Rite® is a registered trademark of X-Rite, Incorporated. All other logos, brand names, and product names mentioned are the properties of their respective holders. RapidMatch is a trademark of PPG Industries Ohio, Inc.
