CY3218-CAPEXP2 C
1
1. Insert the AAA battery.
2. Remove the jumper from J2.
3. Observe that the Power LED
lights up.
3
Insert the kit CD and run the CD's
autorun utility.
®
S
E
AP
ENSE
XPRESS
QUICK START GUIDE
2
1. Observe that the status LED D5
flashes.
2. Slide the finger over the
CapSense slider to light up the
respective LED.
4
Open the guide and install PSoC
Programmer and PSoC Designer.
™ EVALUATION KIT
