CY3218-CAPEXP3 C
Demo#1: CapSense Express Evaluation Board Test
1
1. Insert the AAA battery.
2. Remove the Jumper from J2.
3. Observe that the Power LED
lights up.
3
Insert the kit CD and run the CD's
autorun utility.
®
S
E
AP
ENSE
XPRESS
QUICK START GUIDE
2
Touch the CapSense Buttons to turn
ON the respective LEDs.
4
Open the guide and install software.
™ EVALUATION KIT
