PARAMETER
Physical
Height:
Width:
Depth:
Weight:
Power
Voltage:
Current:
Environmental
Operating Temperature:
Storage Temperature:
Operating and Storage Humidity:
Functional
Characteristic Impedance:
Insertion Loss:
Crosstalk:
Return Loss:
Monitor Level:
Page 1-12
 2001, ADC Telecommunications, Inc.
Table 1-2. System Specifications
SPECIFICATION
7.0 feet (2.13 m)
25.94 inches (65.88 cm)
12 inches (30.48 cm)
360 pounds (163 kg) (Fully equipped)
–48 Vdc
10 mA for each lit LED tracer lamp
–40° to 65° C (–40° to +149° F)
–55° to +85° C (–67° to +185° F)
0% to 95% without condensation
75 ohms unbalanced
Less than 0.8 dB at 22.368 mHz and less than 1.9 dB at 137.088
mHz with up to 27 feet (8.23 m) of cross-connect cable.
Better than –60 dB.
Greater than 20 dB (DC to 300 mHz).
21.5 dB ±1.5 dB below signal level (DC to 300 mHz).
