ADCP-80-353
Issue 2
August 2002
DSX-3 (DSX-4U-24)
Rear Cross-Connect System
Installation Guide
1021186 Rev B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSX-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ADC DSX-3

Summary of Contents for ADC DSX-3

  • Page 1 ADCP-80-353 Issue 2 August 2002 DSX-3 (DSX-4U-24) Rear Cross-Connect System Installation Guide 1021186 Rev B...
  • Page 2 ADCP-80-353 Issue 2 August 2002 DSX-3 (DSX-4U-24) Rear Cross-Connect System Installation Guide 1021186 Rev B...
  • Page 3 DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.

  • Page 4: Table Of Contents

    POWER APPLICATION AND SYSTEM CHECKOUT ..........2-11 SECTION 3: Page iii © 2002, ADC Telecommunications, Inc.
  • Page 5 CUSTOMER INFORMATION AND ASSISTANCE........... 3-3 Page iv © 2002, ADC Telecommunications, Inc.

  • Page 6: About This Manual

    ADCP-80-353 • Issue 2 • August 2002 • Preface ABOUT THIS MANUAL This Installation Guide describes ADC’s DSX-3 (DSX-4U-24) Rear Cross-Connect System and provides all instructions necessary to install the system. RELATED PUBLICATIONS Listed below are related manuals and their publication numbers. Copies of these publications can be ordered by contacting the Technical Assistance Center at 1-800-366-3891, extension 73475 (in U.S.A.
  • Page 7 ADCP-80-353 • Issue 2 • August 2002 • Preface 3 AMP BLOWN FUSE FUSE INDICATOR MAXIMUM 50 AMP MAXIMUM TOTAL BUSS AMPERAGE 8666-A DSX-3 (DSX-4U-24) REAR CROSS-CONNECT SYSTEM Page vi © 2002, ADC Telecommunications, Inc.

  • Page 8: General

    _________________________________________________________________________________________________________ 1 GENERAL This section describes ADC’s DSX-3 (DSX-4U-24) Rear Cross-Connect System and its applications in large and small offices, digital loop carriers, and customer premises. The system provides for test access, patch, cross-connect, and monitor functions in 75 ohm digital transmission systems operating with a common signal format and bit rate.

  • Page 9: Features And Benefits

    2 FEATURES AND BENEFITS Modularity The DSX-3 (DSX-4U-24) Rear Cross-Connect System is modular for easy expansion at the user’s site, and may provide any number of bi-directional cross-connects in multiples of 120 (up to 240 equipment terminations) per 2.13 meter (7 foot) bay. This allows for installation of a minimal system configuration to meet the immediate needs of a site, and then expanding it as necessary by adding individual DSX-4U circuit modules.
  • Page 10 A and B equipment. 3. Split-Circuit Testing - Test equipment patched into an IN or OUT jack splits the A-to-B equipment circuit for direct access testing of either equipment unit. Page 1-3 © 2002, ADC Telecommunications, Inc.

  • Page 11: Physical Description

    = PIN JACK 1267-C Figure 1-2. Typical DSX-3 (DSX-4U-24) Circuit Arrangement 4 PHYSICAL DESCRIPTION Front and rear views of a typical fully configured DSX-3 (DSX-4U-24) Rear Cross-Connect System bay are shown in Figure 1-3 Figure 1-4. The bay is comprised of up to ten module chassis, each capable of holding up to 24 DSX-4U circuit modules.
  • Page 12 ADCP-80-353 • Issue 2 • August 2002 • Section 1: Description 3 AMP BLOWN FUSE FUSE INDICATOR MAXIMUM 50 AMP MAXIMUM TOTAL BUSS AMPERAGE 8666-A Figure 1-3. DSX-3 (DSX-4U-24) Rear Cross-Connect System Bay (Front View) Page 1-5 © 2002, ADC Telecommunications, Inc.
  • Page 13 X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN 8665-A Figure 1-4. DSX-3 (DSX-4U-24) Rear Cross-Connect System Bay (Rear View) Page 1-6 © 2002, ADC Telecommunications, Inc.

  • Page 14: Dsx-4U Circuit Modules

    BNC coaxial connectors at the back of the module are used for connecting the equipment in/out cables and cross-connect jumpers. Specific functions of the circuit module components are defined in Table 1-1. Page 1-7 © 2002, ADC Telecommunications, Inc.
  • Page 15 ADCP-80-353 • Issue 2 • August 2002 • Section 1: Description Table 1-1. DSX-3 (DSX-4U-24) Circuit Module Components NAME TYPE LOCATION FUNCTION Tracer Lamp (TL) Red LED Indicator Front Used to identify the opposite end of a cross-connect. The tracer lamp flashes...

  • Page 16: Dsx-4U Chassis

    MAXIMUM 50 AMP MAXIMUM TOTAL BUSS AMPERAGE FRONT VIEW NEG (–) 1-10 NEG (-) 11-20 – 48V REMOTE ALARMS ONLY POS (+) 1-10 POS (+) 11-20 REAR VIEW 2389-B Figure 1-7. Fuse Panel Page 1-9 © 2002, ADC Telecommunications, Inc.

  • Page 17: Cable Rings And Troughs

    Shelf mounting holes are spaced at 2.54 cm (1 inch). An AC outlet may be provided at the bottom front of the bay as an auxiliary source of 110 Vac primary power. 5 SYSTEM SPECIFICATIONS Specifications for the DSX-3 (DSX-4U-24) Rear Cross-Connect System are shown in Table 1-2.

  • Page 18: General

    POWER APPLICATION AND SYSTEM CHECKOUT ..........2-11 _________________________________________________________________________________________________________ 1 GENERAL This section provides complete instructions for installing the DSX-3 (DSX-4U-24) Rear Cross- Connect System. It is recommended that the entire section be read and understood before beginning installation.

  • Page 19: Power

    ADCP-80-353 • Issue 2 • August 2002 • Section 2: Installation 2.2.2 Operational The DSX-3 (DSX-4U-24) Rear Cross-Connect System must be operated in ambient temperatures and humidities which do not exceed the following: • Temperature: –40° to +65° C (–40° to +149° F).

  • Page 20: Installation

    3.1.1 Positioning and Mounting of New Bay Caution: A crated DSX-3 (DSX-4U-24) Rear Cross-Connect System bay weighs approximately 265 kg (585 pounds). An adequately rated and secured block and tackle or overhead hoist must be used while uncrating, positioning, and securing the bay.

  • Page 21: Circuit Module Installation

    M O N O U T O U T O U T O U T O U T O U T O U T MODULE 8673-A RETAINING SCREWS Figure 2-2. DSX-4U Circuit Module Installation Page 2-4 © 2002, ADC Telecommunications, Inc.

  • Page 22: Installation Of Office/Equipment Cabling

    X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN X-OUT X-IN 8665-A Figure 2-3. Typical Cross-Connect System Cabling Page 2-5 © 2002, ADC Telecommunications, Inc.
  • Page 23 If the cables are coming into the bay from above, cable attachment should start at the bottom and work up (refer to Figure 2-4). NETWORK ELEMENT CABLES 8656-A SPACER FILLER KIT Figure 2-4. Cable Routing from Top to Bottom Page 2-6 © 2002, ADC Telecommunications, Inc.
  • Page 24 IN connector. Secure all cables to the cable bar on the rear of the chassis by use of tie-wraps. Record all equipment terminations on the labels provided on the front of each module. Record cross-connect terminations on the adhesive-backed designation labels provided on the back of the chassis. Page 2-7 © 2002, ADC Telecommunications, Inc.
  • Page 25 –48 Vdc and Ground. (Number 6 compression lug is provided with DSX- FP20F fuse panel.) 3. Complete the connection (step 2) to the –48 V (NEG(–)BUS) and ground (POS(+)BUS) terminals on the fuse panel. See Figure 2-7. Page 2-8 © 2002, ADC Telecommunications, Inc.

  • Page 26: Cross-Connect Jumpers

    Connect the messenger wire pins of this cross connect to the remaining tracer lamp pin jack on each termination. ADC DSX-4U cross-connect jumpers are available in various lengths from 0.3 to 8.23 m (1 to 27 feet). It is important to select the proper cable length to prevent congestion. Cross-connect jumpers are also available with one connector factory terminated and one connector kit which is terminated on site.
  • Page 27 LOWER CROSS- CONNECT WIREWAYS RECOMMENDED SPACING NOTE: BASED ON THE TYPE OF CABLE SELECTED FOR EQUIPMENT IN/OUT CABLING AND CROSS-CONNECT JUMPER, THE ADC RECOMMENDED SPACING IS AS FOLLOWS: APPLICATION EQUIPMENT I/O X-CONN SPACERS REQUIRED FOR UEF BAYS 735A/734A 735A OR RG59 ONE 10-INCH (25.4 CM) BETWEEN BAYS...

  • Page 28: Power Application And System Checkout

    DSX-4U circuit module. Pulling of this button should cause the corresponding tracer lamp and the tracer lamp at the other end of the cross connect to flash for approximately 30 seconds and then remain lit until the button is pushed back in. Page 2-11 © 2002, ADC Telecommunications, Inc.

  • Page 30: Warranty/Software

    Canada) or 952-917-3475 (outside U.S.A. and Canada) for software service agreement information. 3 REPAIR/EXCHANGE POLICY All repairs of ADC Products must be done by ADC or an authorized representative. Any attempt to repair or modify ADC Products without written authorization from ADC voids the warranty.

  • Page 31: Repair Charges

    (30) days to be eligible for any advance replacement credit. If repairs necessitate a visit by an ADC representative, ADC will charge the current price of a field visit plus round trip transportation charges from Minneapolis to the Buyer’s site.

  • Page 32: Customer Information And Assistance

    Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
  • Page 34 www.adc.com...
