DDS Tape Drive

Your DDS tape drive is either a DDS-DC (early or later model) or a DDS-2
tape drive with a 3.5-inch form factor, data compression, and a single-ended
SCSI interface. Both drives incorporate data compression capability and are
high-capacity, high transfer-rate devices for data storage on tape. With com-
pression, the DDS-DC drives can store up to 4 GB of data on a 90 meter tape
and the DDS-2 drive can store up to 8 GB of data on a 120 meter tape.
Figure 3, Figure 4, and Figure 5 show the LEDs, and eject button of the
DDS-format tape drives.
Cassette LED
Figure 3
Tape LED
Figure 4
10
Drive LED
DDS-DC (Early Model) Drive Controls and Indicators
Tape Clean
Clean/Attention LED
DDS-DC (Later Model) Drive Controls and Indicators
DCLZ
Eject Button
Eject Button
