Signify Classified - Internal
After the test is passed, remove the two M12 waterproof screws and put the three pressure relief
valves back in place.
4. Replacing Static/Rotating Gobos
4.1 Replacing Rotating Gobos
1. Unscrew the screws of the luminaire head covers with a Torx screwdriver to open the luminaire
head covers (no need to move the waterproof silicon ring).
2. Unplug the DB plug at A and unscrew the two screws at B to take out the gobo & colors
assembly.
7A
