About This Manual This manual provides descriptions, repair procedures, and illustrated parts breakdowns for all configurations of the VL3000™ Series Luminaire. The manual is intended for use by Vari-Lite personnel and by Vari-Lite’s customers/clients. WARNING: It is important to read ALL accompanying safety and installation instructions to avoid damage to the product and potential injury to yourself or others.
Bulletins are categorized by assembly or subassembly, and identified by a number such as S3K-001 (VL3000 Series Luminaires Technical Bulletin number 1). A list of technical bulletins for these products is found in “VL3000 Technical...
HAPTER Description This chapter contains descriptions of luminaire features and components. • Features • Components • Principles of Operation 02.96 78.001 0 F...
Two, six-position gobo wheels with five rotatable, indexable gobo positions and one open position. • Five-position gobo wheel with four rotatable, indexable positions and one open position. • VL3000Q only: 50% audible reduction in noise output from the VL3000 luminaires. VL3000 and VL3000Q Wash Luminaires • Zoomable beam spreader mechanism. •...
OMPONENTS XTERNAL UMINAIRE OMPONENTS Components External Luminaire Components The following illustration shows the external luminaire components and controls. Upper Enclosure Assembly Houses power supply, ballast, and display board. AC Input Cable Truss Hook Bracket Attaches to enclosure base to allow truss hook installation. Input Panel Provides DMX In and Thru, and AC Power connections.
VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL VL3000 Spot Luminaire Head and Yoke Components The following illustration shows the major sub-assemblies that are located in the luminaire head and yoke assemblies. Head Cover (attached by tether) Gobo Assembly...
: VL3000 W OMPONENTS UMINAIRE EAD AND OMPONENTS VL3000 Wash Luminaire Head and Yoke Components The following illustration shows the major sub-assemblies that are located in the luminaire head and yoke assemblies. Head Cover (attached by tether) Aperture Assembly Used in wash version only.
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Enclosure Components The following illustration shows the major sub-assemblies that are located in the luminaire enclosure assembly. (Yoke and head assemblies not shown for clarity.) Enclosure Top Covers 1200W Arc Ballast Module...
Testing Luminaire Self-Tests The luminaire is capable of running self tests by using the TEST menu functions. For detailed instructions regarding the luminaire’s self-test function, refer to the VL3000 User’s Manual for your luminaire (02.9678.0001 or 02.9678.0005). Calibration Sequence The following is an outline of the luminaire’s standard calibration sequence: Phase 1 •...
Most mechanisms within the VL3000 luminaire are equipped with either optical or magnetic sensors. The VL3000 master control board (MCB) has labeled test points for reading DC voltages at each sensor. Testing is best performed with a digital voltmeter for sensor readings or an oscilloscope for pan/tilt encoder readings.
Page 34
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Notes regarding specific mechanisms: • The four color mixers and dimmer will read high when the tab is in the optical sensor. • The fixed color wheel will read low when the magnet is at the sensor and high at other times.
ROUBLESHOOTING RROR ESSAGES Troubleshooting Error Messages If a problem occurs during luminaire calibration, at the end of the calibration sequence the Menu Display will cycle through any applicable error message(s), one a time until the end of the list is reached.
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Troubleshooting Guide If a problem is suspected, try recalibrating the luminaire to prompt an error message. Refer to “Error Messages” on page 56 for more information. The chart below provides possible causes and remedies for each message.
Page 37
ROUBLESHOOTING ROUBLESHOOTING UIDE Table 2-2: Troubleshooting Guide (Continued) Message Description Symptom Possible Cause and Remedy Pan No Pan Sensor Not Found Luminaire will not pan EOT flag attached to large pulley is not engaging the Sens EOT sensor... - ensure flag is attached to the large pulley. - ensure that flag passes through the sensor at a depth sufficient to engage the sensor beam.
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Maintenance Procedures Lamp Replacement VL Part No: 71.2557.1200 WARNING: Ensure that power is removed from luminaire when installing lamp. CAUTION: Wear cotton gloves or other covering while installing lamp. Touching lamp glass or lamp holder contacts with bare fingers will leave oil and may cause the lamp to explode or reduce lamp life.
Align Lamp The design of the VL3000 luminaire optical system allows for a flat or peaked field. A flat field is one where there is no detectable hot spot and a peaked field is one where the intensity of the beam is greater at the center of the beam than at the perimeter.
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Lamp Power Cut-Off Switch The lower fan duct assembly is equipped with a lamp power cut-off switch. If the hinged duct is raised during operation, the relay automatically disengages and the lamp will douse. When the duct is closed, lamp power is restored.
AINTENANCE ROCEDURES EPLACEMENT Gobo Replacement WARNING: Remove power from luminaire before performing maintenance. Gobos can be HOT after operation. Allow to cool before replacing. WARNING: Users of VARI❋LITE luminaires should not install or use metal gobos. The use of metal gobos in any VARI❋LITE product may damage the luminaire and could void the luminaire’s warranty.
Page 42
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Top Head Cover * Do not touch glass with bare fingers. Press on gobo carrier only. CAUTION: 1/4-Turn Screw Gobo Wheel Gobo Assembly (see detail) Gobo Wheel Front of luminaire...
AINTENANCE ROCEDURES OLOR ILTER EPLACEMENT Color Filter Replacement WARNING: Remove power from luminaire before performing maintenance. Filters may be HOT after operation. Allow to cool before replacing. Repair/Replacement Procedure Step 1. Remove power from luminaire. Step 2. Remove top head cover by loosening four 1/4-turn screws as shown in Figure 2-5.
Step 8. Lift Beam Spreader assembly up through fixture. Step 9. Replace by performing steps 2 through 8 in reverse order. Transfer Fan Assembly Top Head Cover Beam Spreader Figure 2-6: VL3000 Wash Beam Spreader Assembly Replacement 02.96 78.001 0 F...
Step 6. Pull assembly straight up and out of luminaire. Step 7. Replace assembly by performing steps 2 through 6 in reverse order. Top Head Cover Color/Dimmer/Strobe Assembly Clamp Figure 2-7: VL3000 Color/Dimmer/Strobe Assembly Replacement 02.96 78.001 0 F...
Step 5. Disconnect upper enclosure connectors J1, J2, J3, J4 and J12 at back of MCB. Step 6. Install replacement assembly by performing Steps 2-5 in reverse order. Step 7. Configure using menu functions as necessary. Yoke Leg Cover Main Controller Board Figure 2-9: VL3000 Main Control Board Replacement 02.96 78.001 0 F...
Step 4. Using C.K. PLCC extractor tool (see above), replace required stepper motor driver (loca- tions: U27-U30, U32-U44). Step 5. Reinstall Main Control Board PCB performing Steps 2-6 in reverse order from page Stepper Motor Drivers (locations: U27-U30, U32-U44) Figure 2-10: VL3000 Series Motor Drivers on Main Control Board 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Pan Motor Assembly/Pan Belt Replacement VL Part No: 21.9678.0864 (Pan Motor) VL Part No: 54.2055.0001 (Pan Belt) Repair/Replacement Procedure (Pan Motor) Step 1. Using console or internal menus, run lens as far to the rear as possible.
Page 51
Pan Motor Assembly, you must tighten in a CLOCKWISE pattern starting with screw in lower left-hand side from spring. NOTE: Head not shown for clarity. Pan Belt Pan Motor Assembly Bottom Cover Enclosure Bottom View Figure 2-12: VL3000 Pan Motor Assembly Replacement 02.96 78.001 0 F...
Step 7. Replace by performing steps 3 through 6 in reverse order. Note: Make sure the encoder disk passes through the optical sensor. Encoder Disk Encoder Pan Motor Assembly Enclosure Bottom View NOTE: Head not shown for clarity. Bottom Cover Figure 2-13: VL3000 Pan Encoder PCB Replacement 02.96 78.001 0 F...
Step 6. Disconnect wiring from encoder PCB and remove sensor. Step 7. Replace sensor by performing steps 3 through 6 in reverse order. Sensor Pan Motor Assembly Enclosure Bottom View NOTE: Head not shown for clarity. Bottom Cover Figure 2-14: VL3000 Pan EOT Sensor Replacement 02.96 78.001 0 F...
Step 5. Loosen two 6-32x3/8" LG PPZ screws and slide LVS towards upper enclosure fan to remove. Step 6. Replace by performing steps 2 through 5 in reverse order. Top Cover Bottom Cover Power Supply (LVS) NOTE: Head not shown for clarity. Figure 2-15: VL3000 Power Supply (LVS) Replacement 02.96 78.001 0 F...
Step 8. Pull Gobo Assembly straight out of fixture. Step 9. Replace by performing steps 3 through 8 in reverse order. Top Head Cover Gobo Assembly Clamp Optic Assembly (Must be all the way forward.) Figure 2-16: VL3000 Spot Gobo Assembly Replacement 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Gobo Timing Adjustments The index timing belt must be aligned so that the mechanism "clocks" properly. This belt is installed around the index gear and top gear of the gobo wheel. The wheel position belt is installed around the wheel position gear and bottom gear of the gobo wheel, and does not require alignment.
Page 57
AINTENANCE ROCEDURES IMING DJUSTMENTS Position index pulley so large flange is Insert a 3" long #4 or M3 screw (or 0.125" diameter centered in optical sensor pin) completely through aligned holes in wheels and both bulkheads as shown. This will lock the wheels in the "open"...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Gobo Gear Planet Alignment Each gear of the gobo wheel assembly must be aligned so that the gobos will index correctly. Use the following procedure to re-align the gears in the event the gobo wheel is disassembled.
Page 59
AINTENANCE ROCEDURES LANET LIGNMENT 1) Start with center gear timing 2) Rotate center gear clockwise until timing mark mark facing Position 1 (open). is directly across from Position 6. Rotate Position 6 gear until timing marks align. Alignment Mark open Align both marks 4) Verify alignment of all marks 3) Align remaining gobo gears...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Spot Optic Assembly Replacement VL Part No: 22.9678.0103 Repair/Replacement Procedure To remove spot optics assembly: Step 1. Disconnect luminaire AC input cable from power source. Step 2. Remove both top and bottom head covers by loosening four quarter-turn captive locking screws.
Page 61
Motor (see detail) Optic Assembly Side View Motor Edge Screw Clamp Edge Screw (Secure this side Thread all the way into motor first when re- as shown before re-installing. installing.) Figure 2-22: VL3000 Spot Optic Assembly Replacement 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Tilt Motor Assembly and Tilt Belt Replacement VL Part No: 21.9678.0765 (Tilt Motor) VL Part No: 54.2055.0001 (Tilt Belt) Repair/Replacement Procedure To remove and replace tilt motor: Step 1. Disconnect luminaire AC input cable from power source.
Page 63
PPZ screws that mount Pan Motor Assembly, you must tighten in a CLOCKWISE pattern starting with screw in lower left-hand side from spring. NOTE: Head not shown for clarity. Tilt Motor Assembly Sensor Bracket Spring Figure 2-23: VL3000 Tilt Motor Assembly Replacement 02.96 78.001 0 F...
Assembly, you must tighten in a CLOCKWISE pattern starting with screw in lower left-hand side from spring. Tilt Encoder Tilt Motor Assembly Sensor Bracket Spring Tilt Motor Assembly Detail NOTE: Head not shown for clarity. Figure 2-24: VL3000 Tilt Encoder PCB Replacement 02.96 78.001 0 F...
Step 5. At sensor, remove two 6-32x3/8" PPZ screws and remove sensor from bracket. Step 6. Replace by performing steps 2 through 5 in reverse order. Tilt Motor Assembly Sensor Sensor Bracket Spring NOTE: Head not shown for clarity. Figure 2-25: VL3000 Tilt EOT Sensor Replacement 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Ballast Assembly Replacement VL Part No: 23.9678.1269 (Old Style) VL Part No: 12.9678.1862 (New Style) Note: Vari-Lite offers a conversion kit for converting old-style ballasts to new-style ballasts. For information on the kit (VL Part No: 28.9678.0100), see Technical Bulletin S3K-014, "Series 3000™...
Page 67
AINTENANCE ROCEDURES ALLAST SSEMBLY EPLACEMENT Table 3: VL3000 Ballast Connector Locations Location Connector J102 2-Pos Connector J103 3-Pos Mate N Lok J108 Red 1+ (Choke) J109 Dark Blue 2– (Choke) J110 Orange 3+ (Choke) J111 Orange 4– (Choke) J112 8-Pos MTA...
Page 68
Route Lamp to Supply Cable as shown - same as original cable assembly. Back of Display 1200-Watt Ballast Assembly Lamp Supply to Relay Cable Assembly Cable must be routed through Ferrite Figure 2-27: VL3000 Ballast Replacement (New Style) 02.96 78.001 0 F...
: 80MM F AINTENANCE ROCEDURES EPLACEMENT 80MM Fan Replacement VL Part No: 40.7145.0004 Repair/Replacement Procedure Step 1. Disconnect luminaire AC input cable from power source. Step 2. Remove top head cover by loosening four quarter-turn captive locking screws. Top cover is identifiable as the cover on top when back label is such that words are displayed correct side Step 3.
Page 70
80 mm Fan Shield Orientation Series 3000 Back End Assembly 80 mm Fan Assembly Assembly 80MM Fan Assembly Shield Front of Luminaire Shield Orientation: Shield must mimic and cover fan housing. Figure 2-28: VL3000 80MM Fan Replacement 02.96 78.001 0 F...
Step 4. At transfer fan assembly, loosen four 6-32 x 3/8" PPZ screws and slide assembly off Gobo assembly. Step 5. Replace by performing steps 2 through 4 in reverse order. Transfer Fan Assembly Top Head Cover Figure 2-17: VL3000 Transfer Fan Assembly Replacement 02.96 78.001 0 F...
Step 6. Replace by performing steps 2 through 5 in reverse order. Note: Some early-production wash fixtures only have one fan mounted to dual fan assembly. All current production fixtures have two fans. Gobo/Color Fan Assembly Gobo/Color Fan Assembly Figure 2-18: VL3000 Gobo/Color (Dual) Fan Assembly Replacement 02.96 78.001 0 F...
Step 5. Replace by performing steps 2 through 4 in reverse order. Yoke Fan Assembly Yoke Assembly Screws (2 per side) Screws (2 per side) Yoke Fan Assembly NOTE: Some components not shown for clarity. Figure 2-19: VL3000 Yoke Fan Assembly Replacement 02.96 78.001 0 F...
Step 6. At fan, remove three 6-32x3/8" PPZ screws and remove fan. Step 7. Replace by performing steps 2 through 6 in reverse order. Fan Assembly Fan Assembly Display Cover NOTE: Some components not shown for clarity. Figure 2-20: VL3000 Upper Enclosure Fan Assembly Replacement 02.96 78.001 0 F...
HAPTER Illustrated Parts Breakdown This chapter contains illustrated parts breakdowns for all VL3000 assemblies. • Drawing Trees • Top Assembly • Head Assembly • Yoke Assembly • Head/Yoke PCB Assemblies • Enclosure Assembly • Cable Assemblies 02.96 78.001 0 F...
24.9678.3916 Rev 0 Assembly 25.9678.0758 Rev A Yellow Wheel Assembly 22.9678.0474 Rev B Upper Enclosure Assembly 21.9678.0800.01 Rev NN CTO Wheel Assembly 22.9678.0478 Rev B continued next page Figure 3-3: VL3000 Wash Luminaire Subassembly Drawing Tree Part 1 02.96 78.001 0 F...
Page 81
Lamp Supply to Relay Cable Assembly Pan/Tilt Control Cable 25.9678.0829 Rev A Assembly 25.9678.0818 Rev B LVS to Yoke AC Fan Cable Assembly 25.9678.0843 Rev A Figure 3-4: VL3000 Wash Luminaire Subassembly Drawing Tree Part 2 02.96 78.001 0 F...
SSEMBLY TRUCTURE SSEMBLY Head Assembly Head Structure Assembly 21.9678.0600 Rev C 21.9678.0601 Rev A (VL3000 Quiet) Refer to Figure 3-1 Item Qty. Description 10.9678.8620 FRONT CASTING 12.9678.8623 RIGHT SIDE RAIL, MACHINED 12.9678.8625 LEFT SIDE RAIL, MACHINED 21.9678.0615 ASSY, BACKEND 21.9678.0616 ASSY, BACKEND, VL3000 QUIET 53.6515.0001...
SSEMBLY HAFT OTOR SSEMBLY Long Shaft Motor Assembly 21.9678.0243 Rev 0 Refer to Figure 3-9 Item Qty. Description 10.9678.0330 PLATE, MOTOR ADAPTER 44.9678.0249 MOTOR, STEPPER 42MM X 34MM 60MM SHAFT 53.6513.0002 SCREW, 3MM X 5MM LG PFZ METRIC (x4) Figure 3-9: Long Shaft Motor Assembly 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Gobo/Color Fan Assembly - VL3000Q only 21.9678.0659.01 Rev D Refer to Figure 3-13 Item Qty. Description 10.9678.0665 SPRING, EXTENSION ELONGATED HO 22.9678.0661 ASSY, FAN TRAY 22.9678.0665 DUCT ASSY 23.9678.0699 FAN ASSY, HEAD FRONT 53.5506.1375...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Dual Fan Tray/Duct Assembly 21.9678.0660.01 Rev B Refer to Figure 3-13 Item Qty. Description 10.9678.0665 SPRING, EXTENSION ELONGATED HOOK (changed 06-29-06) 22.9678.0661 ASSY, FAN TRAY 22.9678.0665 DUCT ASSY 23.9678.0684 FAN ASSY, HEAD FRONT 53.5506.1375...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Head Front Fan Assembly - VL3000Q only 23.9678.0699 Rev A Refer to Figure 3-14 Item Qty. Description 40.7125.0001 FAN, 24V FAL6F24LH 52.6523.0002 CONN, HOUSING 2POS PLUG SHROUDED WIRE TO WIRE 52.8347.0001...
SSEMBLY RANSFER SSEMBLY Transfer Fan Assembly 21.9678.0678.01 Rev C (Spot) 21.9678.0678.02 Rev C (Wash) Refer to Figure 3-16 Item Qty. Description 10.9678.0679 TRANSFER FAN TRAY 23.9678.0695 FAN ASSY, TRANSFER 53.5506.1375 SCREW, 6-32 X 1-3/8"LG PPB 55.6543.0001 2.12 GROMMET STRIP, SERRATED POLYETHYLENE 55.6769.0004 TWIST-LOK 0.55"...
Page 120
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Notes 02.96 78.001 0 F...
SPIN SHAFT, COLOR WHEEL 10.9678.0332 SLIDING RETAINER 10.9678.0333 RETAINER CLIP 22.9678.1336 FAB ASSY, FIXED WHEEL/CLIP (changed 9-03-03) 41.9678.0305.01 COLOR FILTER, DEEP RED VL3000 41.9678.0305.02 COLOR FILTER, KELLY GREEN VL3000 41.9678.0305.03 COLOR FILTER, CONGO BLUE VL3000 41.9678.0305.04 COLOR FILTER, MAGENTA VL3000 41.9678.0305.05 COLOR FILTER, ORANGE VL3000 41.9678.0305.06...
Page 141
SSEMBLY IXED OLOR HEEL SSEMBLY Fixed Color Wheel Assembly (continued) POS 2 ORANGE POS 3 POS 1 KELLY CONGO GREEN BLUE POS 4 OPEN DARK FUSHIA POS 6 POS 5 DEEP MAGENTA (x6) (x6) (x6) (x6) (x3) Figure 3-32: Fixed Color Wheel Assembly 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Cyan Wheel Assembly 22.9678.0472 Rev C Refer to Figure 3-39 Item Qty. Description 22.9678.0420 PULLEY ASSY, WITH BEARING 41.9678.0471 GLASS, CYAN COLOR WHEEL Painted Timing Mark (Dichroic Coated Side Only)
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Magenta Wheel Assembly 22.9678.0476 Rev B Refer to Figure 3-41 Item Qty. Description 22.9678.0420 PULLEY ASSY, WITH BEARING 41.9678.0475 GLASS, MAGENTA COLOR WHEEL Painted Timing Mark (Dichroic Coated Side Only)
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Color Sense PCB #2 Mount Assembly 22.9678.0489 Rev B Refer to Figure 3-57 Item Qty. Description 10.9678.0452 PCB MOUNT, COLOR SENSE #2 24.9678.3454 PCB ASSY, COLOR SENSOR #2 - 11.9678.0454 PCB, COLOR SENSOR #2 - 52.6447.0010...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL VL3000 Controller PCB 24.9678.3730 Rev 0 This item is only available as an assembly. Figure 3-60: VL3000 Controller PCB 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL DMX Input PCB 24.9663.3830 Rev B Refer to Figure 3-70 Item Qty. Description Ref. 11.9663.1830 PCB FAB, DMX INPUT 52.6259.0006 HEADER, 5POS MTA FRCT LOK STRT POST 52.6625.0006 CONN, RECPT XLR 5P FEM PC MT VERT 52.6626.0006...
Page 190
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Display PCB (continued) Top Side Bottom Side View From Component Side Figure 3-71: Display PCB 02.96 78.001 0 F...
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Pan Pulley Assembly 21.9678.0807 Rev E Refer to Figure 3-73 Item Qty. Description 10.9678.0750 TIMING PULLEY, 2MM GT 150 TOOTH 10.9678.0855 PAN FLAG 53.6530.0009 RIVET, 1/8"OD POP 0.126-0.187GL (changed 10-05-06)
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Head to Back Cap Ground Cable Assembly 25.9661.1522 Rev B Refer to Figure 3-79. Item Qty. Description 52.8311.0003 TERM, RING #6 14-16 AWG NON-INS. TAPE 73.7130.0001 1.33 WIRE, 7/64" TUBULAR BRAID TINNED COPPER...
ABLE SSEMBLIES AN AND ELAY ABLE SSEMBLY Yoke Fan and Relay Cable Assembly 25.9678.0681 Rev C Refer to Figure 3-86 Item Qty. Description 52.6396.3103 RECEPT, 3 POS MTA100 W/ POL TAB BLU CLSD END (changed 05-01-06) 52.6423.0003 HOUSING, 3 POS MT RECEPT, 2MM 52.8230.0003 RECEPT, 1/4"...
: OT S ABLE SSEMBLIES WITCH TO NTERLOK ABLE SSEMBLY OT Switch to Interlok Cable Assembly 25.9678.0682 Rev C Refer to Figure 3-88 Item Qty. Description 52.8371.0001 RECEPT, FASTON 24-20AWG UNISUL TIN PLT BRS .250 X .032 TAB 52.8414.0001 RECEPT, FASTON, 0.187 SERIES 24-20 AWG UNISUL 73.7089.0000 0.79 WIRE, 22AWG 300V 200C TEF BLK UL1180...
ABLE SSEMBLIES OKE TO ROUND ABLE SSEMBLY Yoke to Head Ground Cable Assembly 25.9678.0689 Rev 0 Refer to Figure 3-90 Item Qty. Description 52.8250.0011 TERM, RING #10, 122-10AWG (REEL) 73.7089.0010 15.17 WIRE, 22AWG , 19X34 MIL-16878/4 TYPE E (changed 08-31-06) (7 x 26.0"...
PCB/C ABLE SSEMBLIES NTERCONNECT ABLE SSEMBLY Gobo Interconnect PCB/Cable Assembly 25.9678.2209 Rev 0 Refer to Figure 3-93. Must be ordered as an assembly. Figure 3-93: Gobo Interconnect PCB/Cable Assembly 02.96 78.001 0 F...
: AC I ABLE SSEMBLIES NPUT PLITTER ABLE SSEMBLY AC Input Splitter Cable Assembly 25.9678.0812 Rev E Refer to Figure 3-97 Item Qty. Description 52.6231.0001 PLUG HOUSING, MNLOK PLUG 3POS 52.8231.0005 TERM, RING #6 BLUE 16-14 AWG REEL PIDG 52.8231.0008 TERM, SPADE #6 RED 22-16AWG INSERT 52.8392.0001 RECP, FASTON 0.187"X0.32"...
Page 218
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL AC Input Splitter Cable Assembly (continued) (x2) (x2) 5, 9 5, 10 11, 6 (x3) Figure 3-97: AC Input Splitter Cable Assembly 02.96 78.001 0 F...
I/O L ABLE SSEMBLIES ABLE SSEMBLY Data I/O Link Cable Assembly 25.9678.0813 Rev A Refer to Figure 3-98 Item Qty. Description 52.6396.2904 RECEPT, 4 POS MTA100 W/POL TAB RED CLSD END (changed 05-03-06) 52.6396.2905 RECEPT, 5 POS MTA100 W/POL TAB RED CLSD END (changed 05-03-06) 73.5122.0259 2.17 CBL, 22AWG STRND 4COND PVC INSUL...
: LVS AC F ABLE SSEMBLIES ABLE SSEMBLY LVS to Yoke AC Fan Cable Assembly 25.9678.0843 Rev A Refer to Figure 3-104 Item Qty. Description 52.6664.0001 CONTACT, 22-26AWG FEMALE MATE-N-LOK 2 52.6664.0002 CONN, HOUSING 2 POS CAP MATE-N-LOK 2 52.8231.0008 TERM, SPADE #6 RED 22-16AWG INSERT 55.2186.0001 CABLE TIE, 0.10"...
Page 226
❋ VARI LITE® - VL3000™ S ERIES UMINAIRE ERVICE ANUAL Notes 02.96 78.001 0 F...
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Schematic and Wiring Diagrams Encoder Sensor PCB (Sheet 1 of 1) REVISIONS DESCRIPTION DATE APPD Released per EO # Notes: Unlesss Otherwise specified. All capacitor values are microfarads.
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Solid State Ignitor PCB (Sheet 1 of 1) REVISIONS DESCRIPTION DATE APPD NOTES: UNLESS OTHERWISE SPECIFIED ENGINEERING PROTOTYPE 7/16/02 B.C. 1. ALL CAPACITOR VALUES ARE IN MICROFARADS.
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Gobo Index Sensor PCB (Sheet 1 of 1) REVISIONS DESCRIPTION DATE APPD RLSE TO PRODUCTION ECO 8894 11/08/01 OPB610 B 4B-PH-K VCC_R SENSOR MTG1 MTG2...
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS DMX Input PCB (Sheet 1 of 1) REVISIONS DESCRIPTION DATE APPD Released per EO #09110 9/27/01 NC5FBV SHIELD DMX/VL_IN- DMX/VL_IN+ VL_OUT- VL_OUT+ CHASSIS NC5MBV SHIELD...
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Gobo Interconnect PCB (Sheet 1 of 1) REVISIONS NOTES: UNLESS OTHERWISE SPECIFIED DESCRIPTION DATE APPD 2-103166-3 1. ALL CAPACITOR VALUES ARE IN MICROFARADS. 2. ALL RESISTOR VALUES ARE IN OHMS.
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Color Interconnect PCB (Sheet 1 of 1) REVISIONS NOTES: UNLESS OTHERWISE SPECIFIED DESCRIPTION DATE APPD 1. ALL CAPACITOR VALUES ARE IN MICROFARADS. RELEASED FOR PER EO # 2.
201 REGAL ROW K. FELDHAUS ASSY DALLAS, TEXAS 75247 PCB NO. 11.9678.0454 07-02-02 K.C.F. VL3000 COLOR SENSOR #2 CONFIDENTIAL ALL INFORMATION CONTAINED HEREIN SIZE REVISION DRAWING NUMBER IS THE SOLE AND EXCLUSIVE PROPERTY OF VARI-LITE, INC. AND MAY NOT BE...
DRAWN BY NEXT 201 REGAL ROW ASSY K. FELDHAUS DALLAS, TEXAS 75247 PCB NO. 11.9678.0480 VL3000 COLOR SENSOR #1 CONFIDENTIAL ALL INFORMATION CONTAINED HEREIN SIZE REVISION DRAWING NUMBER IS THE SOLE AND EXCLUSIVE PROPERTY OF VARI-LITE, INC. AND MAY NOT BE...
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Pan/Tilt Encoder PCB (Sheet 1 of 1) REVISIONS NOTES: UNLESS OTHERWISE SPECIFIED DESCRIPTION DATE APPD 1. ALL CAPACITOR VALUES ARE IN MICROFARADS. ENG REL PER EO #09056 6-17-02 K.C.F.
❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS VL3000 Controller PCB (Sheet 1 of 10) REVISIONS DESCRIPTION DATE APPD TEW2 Released to Engineering per EO #09054 5/28/02 T.E.W. Revised per EO #09061 7/3/02 T.E.W.
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Display PCB (Sheet 1 of 1) REV. NO REV. NO REV. NO ECO # ECO # ECO # DESCRIPTION DESCRIPTION DESCRIPTION DATE DATE DATE APPROVED...
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Zoom Interconnect PCB (Sheet 1 of 1) REVISIONS NOTES: UNLESS OTHERWISE SPECIFIED DESCRIPTION DATE APPD 1. ALL CAPACITOR VALUES ARE IN MICROFARADS. RELEASE TO PROD. PER EO #10359 2.
® ❋ VARI LITE - VL3000™ S ERIES UMINAIRE ERVICE ANUAL CHEMATICS AND IRING IAGRAMS Zoom Sensor PCB (Sheet 1 of 1) REVISIONS NOTES: UNLESS OTHERWISE SPECIFIED DESCRIPTION DATE APPD 1. ALL CAPACITOR VALUES ARE IN MICROFARADS. REL. TO PROD. PER EO #09093 2.
PPENDIX Technical Bulletins VL3000 Technical Bulletins The following table identifies the current technical bulletins associated with the VL3000 series luminaires. These improvements have been incorporated into this manual (where applicable) and are available on the Vari-Lite web site at www.vari-lite.com.
