- Page 1 VARl l � �ll l l E VL 1100 LED Luminaire QuickStart Guide...
-
Page 2: About This Guide
Introduction About This Guide This Quickstart Guide is intended for a knowledgeable user to unpack, install, and use the VL1100 LED™ Luminaire in a short time period. For the complete manual in PDF format, please visit our web site at www.philips.com/entertainmentlighting... -
Page 3: Safety Notice
UV RADIATION, AND INJURY TO PERSONS CAN BE FOUND BELOW. WARNING: INSTRUCTIONS FOR CONTINUED PROTECTION AGAINST FIRE VARI❋LITE luminaires have been designed for use with specific lamp types. The VL1100 LED Luminaire requires a certain type of lamp (see “Replacement Items/Accessories” on page 8 for all lamp types). -
Page 4: Notes De Sécurité
VARI❋LITE - VL1100 LED L UMINAIRE UICK TART UIDE WARNING: RF INTERFERENCE This is a Class B product. In a domestic environment this product may cause radio interference, in which case, the user may be required to take adequate measures. -
Page 5: Replacement Items/Accessories
Product AC Input Connector (this document) Registration Figure 1: VL1100 LED Luminaire Included Items Replacement Items/Accessories The following optional and/or replacement items can be ordered directly from your Authorized VARI❋LITE Dealer. When ordering, please order by the Vari-Lite part number. -
Page 6: Connecting Power And Data
VARI❋LITE - VL1100 LED L UMINAIRE UICK TART UIDE Connecting Power and Data Connecting Power The luminaire requires standard AC power distribution from 100-240 VAC, 50/60 Hz. Current required depends on the AC supply voltage and product model. Refer to “Current vs. -
Page 7: Current Vs. Voltage
Current vs. Voltage Table 1-1, VL1100 LED Luminaire - Current vs. Voltage (460W LED Source) provides the luminaire’s current draw at specific voltages. Total Luminaire Current is calculated with the lamp on and all motors sequencing. - Page 8 VARI❋LITE - VL1100 LED L UMINAIRE UICK TART UIDE Step 3. At last luminaire in link, install male termination connector at DATA THRU connector. (Luminaires and other devices on the same DMX chain may not function properly without termination.) AC In...
-
Page 9: Installation Procedures
Hanging the Luminaire The VL1100 LED™ Luminaire be hung horizontally or vertically from any structure designed to work with the type of load created by this moving luminaire. The pan tube base provides two mounting holes for attaching truss hooks or other mounting hardware as required. Many compatible truss hooks are available from different manufacturers for your particular needs. - Page 10 May be required by local codes. 17.5” (44.5cm) 34.5” (87.6cm) 26” (66cm) Figure 5: Example VL1100 LED Luminaire Truss Hanging Installation 24 A p r i l 2 0 1 7 0 2 . 1 6 0 2 . 0 0 0 1...
-
Page 11: Menu Controls
TART UIDE Menu Operation LCD Display and Menu System The VL1100 LED Luminaire’s LCD Display and Menu System provides local control for accessing the following fixture’s settings: • Address – to set the DMX address • Setup – to change any modes •... -
Page 12: Menu Default State
VARI❋LITE - VL1100 LED L UMINAIRE UICK TART UIDE For example, the Address function has one sub-level: DMX. This 2nd level menu allow access to a 3rd level, which is a value. The Address function is a three-level menu. 1st Level... - Page 13 VL1100 LED I / LED HP I - DMX Channel Summary Listing VL1100 LED S / LED HP S - DMX Channel Summary Listing. Table 1-2: VL1100 LED I / LED HP I - DMX Channel Summary Listing Description Description Channel...
