The Expansion Power Supply (XPS)

XPS Features
Figure 1, below, is an illustration of the XPS.
POWER/ COMMS
AC STATUS LED
OUTPUT TO
(LED4)
NEXT PDI (P2)
P2
LED4
TB2
0V
2 A
24V
TROUBLE LED
AUXILIARY
POWER INPUT
(TB2)
COMM TROUBLE
LED (LED6)
PDI CONNECTOR
(reverse side)
BATTERY
SIGNAL POWER
CONNECTOR (P1)
(LED5)
DEVICE
ADDRESS DIP
SWITCH (SW1)
Figure 1. The Expansion Power Supply
4
firealarmresources.com
NAC TERMINAL
BLOCK (TB1)
XNAC
CONNECTOR
(P3)
NAC STATUS
LEDs:
LED1
P3
LED2
LED3
3 A (NAC)
2 A (AUX)
3 A (NAC)
2 A (AUX)
3 A (NAC)
2 A (AUX)
