This publication provides an overview of the features, specifications, and capabilities of the
Introduction
TrueAlert
three Signaling Line Circuits (SLC). Each of which provides control and power to the full range
of TrueAlert appliances.
The TrueAlert power supplies are identical to each other with the following exceptions:
If you are wiring Class A circuits, you need to install a 4100-5124 Class A Adapter Card onto the
TrueAlert Power Supply before installing the power supply. Refer to Document # 579-337 for
more information.
This product is compatible with the 4100U and 4100ES Fire Alarm Control Panel (FACP).
IMPORTANT: Verify FACP System Programmer, Executive, and Slave Software
In this Publication
This publication discusses the following topics:
2001-2011 SimplexGrinnell LP. All rights reserved.
Specifications and other information shown were current as of publication and are subject to change without notice.
Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license..
®
power supplies (TPS). These supplies provide auxiliary power, a battery charger, and
4100-5120 Domestic (US) version, requires a 120 VAC power source.
4100-5121 Canadian version, requires 120 VAC power source and provides battery cutout
option. After installing a 4100-5121, refer to "Enabling Low Battery Cutout Option" in
the ES Panel Programmer's Manual (574-849) for information on enabling this option.
4100-5122 International version, uses a 220/240 VAC power source.
compatibility when installing, or replacing system components.
Refer to the Technical Support Information and Downloads website
for compatibility information.
firealarmresources.com
4100-5120/5121/5122
TrueAlert
Installation Instructions
Topic
®
Power Supply
See Page #
2
3
6
7
9
10
12
14
17
20
21
579-336
Rev. K

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TrueAlert 4100-5120 and is the answer not in the manual?

Questions and answers

Summary of Contents for Simplex TrueAlert 4100-5120

  • Page 1: Table Of Contents

    579-336 Specifications and other information shown were current as of publication and are subject to change without notice. Rev. K Simplex and the Simplex logo are trademarks of Tyco International Ltd. and its affiliates and are used under license.. firealarmresources.com...
  • Page 2: Cautions And Warnings

    DO NOT INSTALL ANY SIMPLEX® PRODUCT THAT APPEARS DAMAGED - Upon unpacking your Simplex product, inspect the contents of the carton for shipping damage. If damage is apparent, immediately file a claim with the carrier and notify an authorized Simplex product supplier.
  • Page 3: Introduction To The Tps

    Introduction to the TPS Overview The features of the TrueAlert Power Supply are:  Three Signaling Line Circuits. The TPS provides uninterruptible power and control to three separate channels of TrueAlert addressable notification appliances. Each channel is referred to as a Signaling Line Circuit (SLC) and is power limited, power limited is defined in NFPA 70 (National Electric Code).
  • Page 4 Introduction to the TPS, Continued  Additional Features Full TrueAlert Operation. TrueAlert addressable notification appliances are individually addressed and receive power, supervision, and control signals over the SLC. Horns sound with selectable high or low output, using a temporal, march time (60 or 120 beats per minute), or continuous pattern.
  • Page 5 Introduction to the TPS, Continued TPS Current Table 2 lists the battery standby requirements for the TPS. The voltage is 24 VDC, which is the rated Consumption battery voltage for lead-acid type batteries. Table 2. Battery Standby Conditions Current Standby – no alarms, SLCs normal 88 mA Standby –...
  • Page 6: Mounting

    Mounting Overview The TPS mounts onto the right side of an expansion box, and connects to the Power Distribution Interface (PDI). Mounting Procedure 1. Slide the two tabs on the bottom of the TPS into the rightmost two slots on the expansion bay. 2.
  • Page 7: Configuring The Tps

    Configuring the TPS Setting Earth Fault The Earth Fault Enable/Disable jumper allows you to enable or disable positive and negative Earth Enable/Disable Fault detection. Jumper Place the jumper block on Pins 1 and 2 to enable Earth fault detection. Place the jumper block on Pins 2 and 3 to disable Earth fault detection.
  • Page 8 Configuring the TPS, Continued Setting Address Switch Table 3. Card Addresses Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 Address SW 1-2 SW 1-3 SW 1-4 SW 1-5 SW 1-6 SW 1-7 SW 1-8 firealarmresources.com...
  • Page 9: Power Distribution Module/Battery Connections

    Power Distribution Module/Battery Connections Overview The TPS gets its power from the Power Distribution Module (PDM). The PDM takes power directly from a dedicated AC line and the two backup batteries, and distributes power to each bay in the cabinet. Power Distribution The Power Distribution Module (PDM) connects to every power supply in each back box.
  • Page 10: Compatible Truealert Devices

    Compatible TrueAlert Devices Compatible The following table lists compatible TrueAlert devices. All devices are rated one unit load, with the TrueAlert Devices exception of the Isolator Module (4905-9929) that is rated three unit loads. Note: If you are connecting devices to the 4100-5121 (Canadian) TPS, you must only attach TrueAlert compatible, ULC listed devices.
  • Page 11 Compatible TrueAlert Devices, Continued Compatible Table 4. Compatible TrueAlert Devices (continued) TrueAlert Devices Installation Device Document # Strobe Multi-Candela (15, 30, 75, 110) – 4906-9201 579-808 Strobe Multi-Candela (15, 30, 75, 110) – 4906-9203 579-808 White Strobe Multi-Candela (15, 30, 75, 110) 4906-9202 579-808 Ceiling–...
  • Page 12: General Wiring Guidelines

    General Wiring Guidelines  General Wiring Use only copper conductors for all wiring applications. All equipment must be installed in Guidelines accordance with the manufacturer’s recommendations and the specifications and standards of the authority having jurisdiction (AHJ). The installation of all wiring, cable, and equipment must be in accordance with NFPA 70 and the National Electrical Code (NEC), specifically Article 760 (Fire Alarm Systems), Article 800 (Communications Circuits).
  • Page 13 General Wiring Guidelines, Continued Power-Limited/Non- Adhere to these guidelines when wiring power limited and non-power limited wiring within the FACP. Power Limited Wiring Guidelines  Non-power limited field wiring (AC power, batteries) must be installed and routed in the shaded areas shown in the figure below. ...
  • Page 14: Wiring Class A Circuits

    Overvoltage suppressors are required when wiring leaves the building. Use Simplex Model 2081-9028 for wire distances of up to 1,000 feet (305 m). Use Simplex Model 2081-9044 for long wire distances and light alarm loads. Note that the 6 Ohm line resistance of Simplex Model 2081-9044 will decrease the distances given in Table 5.
  • Page 15 Wiring Class A Circuits, Continued Class A Guidelines The table below shows the maximum SLC wire lengths based on wire gauge and appliance current load. Table 5. Maximum SLC Wire Length to Farthest Appliance Based on Appliance Current Load Distance in Feet (Meters) to the Last Appliance Alarm Current 18 AWG (0.82 mm 14 AWG (2.08 mm...
  • Page 16 firealarmresources.com...
  • Page 17 Wiring Class A Circuits, Continued FigureTag FD9-336-03 Class A Wiring Diagram TRUEALERT TRUEALERT TRUEALERT (No Isolators) APPLIANCE APPLIANCE APPLIANCE Ferrite Bead Ferrite Bead Figure 6. Class A Wiring, No Isolators Class A FigureTag FD9-336-04 Wiring Diagram 4905-9929 (With Isolators) ISOLATOR PORT PORT TRUEALERT...
  • Page 18: Wiring Class B Circuits

    Wiring Class B Circuits  Class B Guidelines Only TrueAlert appliances and accessories (“Devices”) are allowed on these SLCs. Refer to Table 4 for a list of compatible TrueAlert devices and to the TrueAlert Device Installation Instructions for connection details. ...
  • Page 19 Continued on next page firealarmresources.com...
  • Page 20 Wiring Class B Circuits, Continued Class B Guidelines The table below shows the maximum SLC wire branch length based on supervision communications. Table 8. Maximum SLC Wire Branch Length Based on Supervision Communications Distance in Feet (Meters) to the Last Appliance Unit Load Range 18 AWG (0.82 mm 14 AWG (2.08 mm...
  • Page 21 Wiring Class B Circuits, Continued Class B For Class B wiring with isolators, T-Tapping is allowed. SLC wiring may be split multiple times to Wiring Diagram form SLC wire branches. Maximum wire distance of each of these SLC branches from panel to any (With Isolators) device is the smaller of the values obtained from Table 8 and the Equation 1 shown below.
  • Page 22: Wiring Aux Power

    Wiring AUX Power Wiring Diagram to Supervision must be provided if the auxiliary power circuit is to be wired as a power-limited circuit. Connect AUX Power In order to connect a circuit using power-limited wiring, the devices being powered must all be to Power Limited addressable, or a UL Listed EOL relay must be used to supervise the circuit.
  • Page 23: Troubleshooting

    Troubleshooting System Trouble The system trouble indicators consist of a bank of five yellow LEDS (refer back to Figure 1 for their Indicators location on the TPS). These LEDs are used to signal various trouble conditions on the TPS and its (LEDs A through E) SLCs.
  • Page 24 579-336 Rev. K firealarmresources.com...
