Summary of Contents for Siargo MF5806E1
- Page 1 Medical Oxygen Flow Meter VA.0.01 Model MF5806E1 @ 2022 Siargo Ltd. www.Siargo.com...
- Page 2 Santa Clara, CA 95054 Tel: +1(408)969.0368 Email: info@siargo.com © Copyright 2022 by Siargo Ltd. Siargo Ltd. and its subsidiaries reserve the right to change the specifications and/or descriptions without prior notice. For further information and updates, please visit: www.Siargo.com www.Siargo.com MF5806E1 User Manual...
- Page 3 However, training of the operator should be performed before use . x LoRaWAN wireless is a local network, excellent for data safety and reliability. Some knowledge of the system is required for the communication. www.Siargo.com MF5806E1 User Manual P a g e...
-
Page 4: Table Of Contents
5.4.13 Reset the time counter ..................... 17 5.4.14 Exit the MENU ........................ 18 5.4.15 Sleeping mode ........................ 18 5.4.16 Wake up the meter ......................18 5.4.17 MENU key sequence for the settings ................. 19 www.Siargo.com MF5806E1 User Manual P a g e... - Page 5 Comparison with a third-party reference meter ..............27 8. Troubleshooting ..................29 9. Warranty and Liability ................30 10. Service/order contact and other information ..........32 Appendix I: LoRaWAN connection ..............33 Appendix II: Document history ............... 34 www.Siargo.com MF5806E1 User Manual P a g e...
-
Page 6: Overview
The MF5806E1 is designed to be a significant improvement of the oxygen therapy process into a fully automatic with remote data and execution. The precision control via an oxygen mass flow meter is enabled with the company’s proprietary MEMS (micro-electro-mechanical systems) thermal... -
Page 7: Receipt / Unpack Of The Products
Adapter Data cable Figure 2.1: MF5806E1 flow meter and accessories Please check immediately for the integrity of the product as well as the accessories listed above and based on your actual order, if any abnormal is identified, please notify the distributor/sales representative or manufacturer as soon as you can. -
Page 8: Knowing The Products
Water bottle Oxygen output Figure 3.1: MF5806E1 parts description 3.2 LCD description The LCD provides all information that the product measures. The following table details the meaning of each of the symbols. Figure 3.2: MF5806E1 LCD display Table 3.1: Symbols description... -
Page 9: Power And Data Cable Description
3.3 Power and data cable description Table 3.2: MF5806E1 wire assignment. Wire Color Definition Power supply (+24 Vdc) Black GND, ground Green RS485A (+) White RS485B (-) Figure 3.3: MF5806E1 data cable 3.4 Mechanical dimensions Note: The water cup size may be different from region to region. -
Page 10: Installation
Once the battery is installed, or the external power is successfully connected, the LCD will be lighted up and flash for about 2 seconds before the proper information is displayed correctly. g) This will conclude the installation. www.Siargo.com MF5806E1 User Manual P a g e... - Page 11 Make sure no mechanical stresses in the connections. d) The strong electromagnetic interference sources close by or any mechanical shocks at the pipeline may also create malfunctioning of the product. www.Siargo.com MF5806E1 User Manual 10 | P a g e...
-
Page 12: Operation And Menu Description
It is recommended such a feature to ensure the cable is properly engaged and will not be accidentally got unplugged. Half-duplex RS485 Modbus is used for digital data communication. Make sure the wires are properly connected to the receiver side. www.Siargo.com MF5806E1 User Manual 11 | P a g e... -
Page 13: Meter Menu Description
5.4 Meter MENU description MENU Down Figure 5.1: MF5806E1 keys description The meter has a front 3-key board for the user to set the desired functions, access data, and check the status. The Menu key (M) is at the central position that allows the user to select a function and confirmation or other related actions that will be detailed below. -
Page 14: Menu Entry With A Verified Password
“M” key to enter into the change address screen. Press the “Up” or “Down” key to change the flashing digits, and then press the “M” key to confirm. After the address is set, the display will return to F2 - www.Siargo.com MF5806E1 User Manual 13 | P a g e... -
Page 15: Set The Rs485 Communication Baud Rate
F11 - oFFST screen, which indicates the task is completed. Use the “Up” or “Down” key to select F99 - qUIT and the “M” key to exit the MENU and return to the Main Display screen. www.Siargo.com MF5806E1 User Manual 14 | P a g e... -
Page 16: Set The Response Time
Use the “Up” or “Down” key to select F99 - qUIT and the “M” key to exit the MENU and return to the Main Display screen. www.Siargo.com MF5806E1 User Manual 15 | P a g e... -
Page 17: Set An Alarm: Lower The Instant Flow Rate Limit
The display will then return to the F53 - ALm-A screen, which indicates the task is completed. Use the “Up” or “Down” key to select F99 - qUIT and the “M” key to exit the MENU and return to the Main Display screen. www.Siargo.com MF5806E1 User Manual 16 | P a g e... -
Page 18: Change The Default Password
“M” confirming key to execute, and press the “M” key again to complete the task. The display will then return to the F93 - CLr-T screen, which indicates the task is completed. Use the www.Siargo.com MF5806E1 User Manual 17 | P a g e... -
Page 19: Exit The Menu
When the meter is in sleeping mode, it will automatically wake up if the flow rate in the flow channel is larger than 0.5 L/min for 10 seconds. Or the meter can be waked up manually by pressing any of the three keys on the front meter face. www.Siargo.com MF5806E1 User Manual 18 | P a g e... -
Page 20: Menu Key Sequence For The Settings
5.4.17 MENU key sequence for the settings Figure 5.3: MF5806E1 MENU key sequence www.Siargo.com MF5806E1 User Manual 19 | P a g e... -
Page 21: Rs485 Modbus Communication Protocol
(PC or PLC) can communicate with multiple slaves (the current product) for data exchange and communication parameter configuration. 5.5.1 Hardware connection The hardware layer is TIA/EIA-485-A, as illustrated below. In this configuration, the product (MF5806E1) is a slave. 5.5.2 Communication parameters The PC UART communication parameters are listed in the following table. Protocol... -
Page 22: Frame
Write multiple registers 5.5.5 Registers product (MF5806E1) has multiple registers available for the assignment of the various functions. With these functions, the user can obtain the data from the products, such as product address and flow rates from the registers, or set the product functions by writing the corresponding parameters. - Page 23 20.340 SLPM, the user will read “0” from register Notes 0x003A and “20340” from register 0x003B, therefore Current flow rate = (0*65536+20340)/1000 = 20.340 www.Siargo.com MF5806E1 User Manual 22 | P a g e...
- Page 24 Value type UINT 32 Alarm values = Value (0x0096)*65536 + Value (0x0097) When the set value is reached, an alarm will be triggered. Notes Note: need to disable the write protection. www.Siargo.com MF5806E1 User Manual 23 | P a g e...
- Page 25 Reset the accumulated or totalized flow rate value Value type UINT 16, Fixed value 0x0001 To reset the accumulated or totalized flow rate value, write 0x0001 to register 0x00F2. Notes Note: need to disable the write protection. www.Siargo.com MF5806E1 User Manual 24 | P a g e...
- Page 26 0x00FF, and then the write function will be enabled (write protection is Notes disabled). After the write execution is completed, the firmware will automatically re-enable the write protection. Note: Only Address and Baud rate will not be write-protected. www.Siargo.com MF5806E1 User Manual 25 | P a g e...
-
Page 27: Technical Specifications
Power consumption >60 (on batteries) Reference conditions 20°C, 101.325 kPa, air Power / data interface USB Type-C Mechanical connection DISS or customer specified Fluid compatibility Oxygen Protection IP50 EN61326-1; -2; -3 www.Siargo.com MF5806E1 User Manual 26 | P a g e... -
Page 28: Technical Notes For The Product Performance
(about 1/3 of the product), and pay special attention to the differences in the reading accuracy and full-scale accuracy. A full scale accuracy = reading accuracy x (full scale flow rate/ set point (current) flow rate) www.Siargo.com MF5806E1 User Manual 27 | P a g e... - Page 29 Therefore, it would be very critical to have the system not have a pressure variation. (This explains our recommendations for the installations in Section 4). Also, the meter measurement principle is often very important for the understanding of any discrepancies. www.Siargo.com MF5806E1 User Manual 28 | P a g e...
-
Page 30: Troubleshooting
Vibration, unstable flow Check system Offset unstable Circuitry instability Check system, power off No digital interface Wrong address, software Check commands, connection No wireless Wrong model, data jam Check model, power off/on www.Siargo.com MF5806E1 User Manual 29 | P a g e... -
Page 31: Warranty And Liability
The products returned under warranty to Siargo shall be at the user or purchaser's risk of loss and will be returned, if at all, at Siargo's risk of loss. Purchasers or users are deemed to have accepted this limitation of warranty and liability, which contains the complete and exclusive limited warranty of Siargo. - Page 32 (5) Any damages incurred by the incorrect usage of the products; (6) Siargo does not provide any warranty on finished goods manufactured by others. Only the original manufacturer's warranty applies;...
-
Page 33: Service/Order Contact And Other Information
10.Service/order contact and other information Siargo Ltd. is making every effort to ensure the quality of the products. In case of questions and or product support, please contact your direct sales, or in case you need additional assistance, please contact customer service at the address listed below. We will respond to your request in a timely fashion and work with you toward your complete satisfaction. -
Page 34: Appendix I: Lorawan Connection
Users can directly plug the station into the USB port of the computer, connect the power adapter provided, and place the antenna in an open space without excessive blockage. With the demo software supplied, users can plug and play. www.Siargo.com MF5806E1 User Manual 33 | P a g e... -
Page 35: Appendix Ii: Document History
Appendix II: Document history Revision A0.01 (July 2022) ¾ Update service contract information. Revision VA.0 (February 2022) ¾ First release. www.Siargo.com MF5806E1 User Manual 34 | P a g e...
