Elbow support 10-366
Elbow support 10-366 including versions
Version
10-366
10-366-UK
10-366-US
Warning!This symbol indicates important information related to safety. Follow these
instructions carefully.
Read User Manual before use! It is important to fully understand the content of the user
manual before attempting to use the equipment.
2020-10-30
Document number: M10-366EN rev.01
1
Description
Clamp (EU 25x10 mm rail)
Clamp (UK 1¼ " x ¼ " rail)
Clamp (US 1⅛ '' x ⅜ '' rail)
Advertisement
Table of Contents
Related Manuals for Reison 10-366
Summary of Contents for Reison 10-366
- Page 1 Elbow support 10-366 Elbow support 10-366 including versions Version Description 10-366 Clamp (EU 25x10 mm rail) 10-366-UK Clamp (UK 1¼ ” x ¼ ” rail) 10-366-US Clamp (US 1⅛ ’’ x ⅜ ’’ rail) Warning!This symbol indicates important information related to safety. Follow these instructions carefully.
- Page 2 Intended use Elbow support intended for support to the surgeon or supporting staff during surgery. The product is to be used by medical professionals within a medical facility. Safety regulations Maximum load: 15 kg for maintained safety factor according to EN 60601-1 och EN 60601-2. Before use, ensure correct function! Remove the elbow support or secure it over the operating table, during transport! Service and preventive maintenance shall be performed by authorized personnel.
- Page 3 User instruction Installation Position adjustment...
- Page 4 Maintenance Service, preventive maintenance, adjustment and repair shall be performed by authorized personnel only. Altering the construction without a written consent from the manufacturer, is strictly forbidden. Cleaning Clean with antiseptic detergent with pH 6 – 8 and warm water. Ethanol can be used on metal surfaces. Wipe dry with soft cloth.
- Page 5 Spare parts Version: 10-366 10-366-UK 10-366-US Description Article no. Article no. Article no. Inner arm 10398 10398 10398 Pivot fitting 10300 10300 10300 Outer arm 10399 10399 10399 Post 10400 10400 10400 10425 10425 10425 Locj lever GN 300 78S M8x16...
- Page 6 Technical specification Maximum workload 15 kg Weight 3,5 kg Dimension (H x W x L) 300 x 200 x 640 mm Material elbow support Stainless steel Version UDI-DI 10-366 07350111831516 10-366-UK 07350111831523 10-366-US 07350111831530...
- Page 7 Reison Medical AB Eriksbergsvägen 32A 734 92 Hallstahammar SWEDEN +46 (0)220 433 99 order@reison.se info@reison.se...
