3 Interface Devices and Mass-Storage Drives
S3 Trio 64V2 Graphics Controller Chip

Available Video Resolutions

The following table lists the available video resolutions using the current
drivers. The available resolutions may be different with later versions of
driver.
Resolution
Windows NT 640 x 480
800 x 600
1024 x 768
1280 x 1024
1600 x 1200
1.
Interlaced.
If Video Plug and Play is
Setup will automatically configure the best refresh rate. For non DDC
monitors, or when video Plug and Play is
changed in Setup.
The number of colors supported is limited by the graphics board and the
video RAM. The resolution/refresh-rate combination is limited by a
combination of the display, the graphics board, and the video RAM.

Connectors

The layout of the pins for the DB15 VGA socket is depicted on page 42.
The Video Electronics Standards Association (VESA) defines a standard
video connector, variously known as the VESA feature connector,
auxiliary connector, or pass-through connector. This connector (whose
pin names are listed in a table on page 40) is integrated on the system board,
and is connected directly to the pixel data bus and the synchronization
signals.
The graphics controller supports an output-only VESA feature connector in
VGA mode. It is disabled by default and must be enabled in the Setup
program. Use of the VESA feature connector will disable 1 MB of the video
memory; with access only to the remaining 1 MB of video memory, some of
the video resolutions will not be available.
38
Number of colors
16
256, 64K, 16M
256, 64K, 16M
256, 64K
256
256
in Setup, and a DDC monitor is detected,
enabled
disabled
Refresh Rate (Hz)
60
60, 72, 75, 85
60, 72, 75, 85
1
i43 , 60, 70, 75, 85
1
i45 , 60, 75, 85
1
i48 , 60
, refresh rates can be
